| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (56B-13-10002) | TORQFLOW ASS'Y | 1 | SN: (100063)-0001076) |
|||
| ? | (56B-13-10001) | TORQFLOW ASS'Y | 1 | SN: (0005)-(100062) |
|||
| ? | (56B-13-10000) | TORQFLOW ASS'Y | 1 | SN: (1001-(0004) |
|||
| ? | THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 56B-15-18113 | • TUBE | 1 | SN: (0022)-0001076) |
|||
| ? | 56B-15-18112 | • TUBE | 1 | SN: (1001-(0021) |
|||
| ? | 56B-15-18122 | • TUBE | 1 | SN: (0022)-0001076) |
|||
| ? | 56B-15-18121 | • TUBE | 1 | SN: (1001-(0021) |
|||
| ? | 56B-15-18131 | • TUBE | 1 | SN: (0022)-0001076) |
|||
| ? | 56B-15-18130 | • TUBE | 1 | SN: (1001-(0021) |
|||
| ? | 56B-15-18142 | • TUBE | 1 | SN: (0022)-0001076) |
|||
| ? | 56B-15-18141 | • TUBE | 1 | SN: (1001-(0021) |
|||
| ? | 56B-15-18172 | • TUBE | 1 | SN: (0022)-0001076) |
|||
| ? | 56B-15-18171 | • TUBE | 1 | SN: (1001-(0021) |
|||
| ? | 20U-62-42210 | • NIPPLE | 8 | SN: (0022)-0001076) |
|||
| ? | 10E-60-16141 | • NIPPLE | 8 | SN: (1001-(0021) |
|||
| ? | 02782-10516 | • ELBOW | 2 | SN: (0022)-0001076) |
|||
| ? | 07235-10422 | • ELBOW | 2 | SN: (1001-(0021) |
|||
| ? | 02896-61015 | • O-RING (K3) | 10 | SN: (0022)-0001076) |
|||
| ? | 07002-12034 | • O-RING (K3) | 10 | SN: (1001-1076) |
|||
| ? | 56B-15-18711 | • BRACKET | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-18720 | • BRACKET | 1 | SN: (1001-1076) |
|||
| ? | 04434-51510 | • CLIP | 3 | SN: (1001-1076) |
|||
| ? | 01010-81020 | • BOLT | 1 | SN: (1001-1076) |
|||
| ? | 01435-01016 | • BOLT | 3 | SN: (1001-1076) |
|||
| ? | 01010-81045 | • BOLT | 2 | SN: (1001-1076) |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: (1001-1076) |
|||
| ? | 56B-15-18150 | • TUBE | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-18160 | • TUBE | 1 | SN: (1001-1076) |
|||
| ? | 07206-31824 | • BOLT | 4 | SN: (1001-1076) |
|||
| ? | 07005-02416 | • GASKET (K3) | 8 | SN: (1001-1076) |
|||
| ? | 56B-15-18181 | • TUBE | 1 | SN: (1001-1076) |
|||
| ? | 07206-31520 | • BOLT | 2 | SN: (1001-1076) |
|||
| ? | 07005-02012 | • GASKET (K3) | 4 | SN: (1001-1076) |
|||
| ? | 42A-16-11210 | • PLATE | 1 | SN: (1001-1076) |
|||
| ? | 04434-51810 | • CLIP | 1 | SN: (1001-1076) |
