| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (56B-13-10002) | TORQFLOW ASS'Y | 1 | SN: (100063)-0001076) |
|||
| ? | (56B-13-10001) | TORQFLOW ASS'Y | 1 | SN: (0005)-(100062) |
|||
| ? | (56B-13-10000) | TORQFLOW ASS'Y | 1 | SN: (1001-(0004) |
|||
| ? | THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 56B-15-12040 | • DIFFERENTIAL ASS'Y | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-17410 | • • GEAR | 4 | SN: (1001-1076) |
|||
| ? | 56B-15-17510 | • • SHAFT | 4 | SN: (1001-1076) |
|||
| ? | 07043-70108 | • • PLUG | 4 | SN: (1001-1076) |
|||
| ? | 04260-00635 | • • BALL | 4 | SN: (1001-1076) |
|||
| ? | 154-15-49510 | • • RING | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-19450 | • • BEARING | 8 | SN: (1001-1076) |
|||
| ? | 56B-15-17550 | • • WASHER,THRUST | 8 | SN: (1001-1076) |
|||
| ? | 56B-15-17311 | • • CARRIER | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-17211 | • • SHAFT,REAR | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-17221 | • • SHAFT,FRONT | 1 | SN: (1001-1076) |
|||
| ? | 198-15-26510 | • • PLUG | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-12563 | • • GEAR,OUTPUT | 1 | SN: (0030)-0001076) |
|||
| ? | 56B-15-12562 | • • GEAR,OUTPUT | 1 | SN: (0005)-(0029) |
|||
| ? | 56B-15-12561 | • • GEAR,OUTPUT | 1 | SN: (1001-(0004) |
|||
| ? | 01010-61655 | • • BOLT | 24 | SN: (1001-1076) |
|||
| ? | 01643-31645 | • • WASHER | 24 | SN: (1001-1076) |
|||
| ? | 04020-01842 | • • PIN | 2 | SN: (1001-1076) |
|||
| ? | 56B-15-17611 | • • RING GEAR | 1 | SN: (1001-1076) |
|||
| ? | 04070-00115 | • • RING | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-17250 | • • GEAR,SUN | 1 | SN: (1001-1076) |
|||
| ? | 04064-07025 | • • RING | 2 | SN: (1001-1076) |
|||
| ? | 56B-15-17131 | • • HOUSING,DIFFERENTIAL | 1 | SN: (1001-1076) |
|||
| ? | 07043-70108 | • • PLUG | 2 | SN: (1001-1076) |
|||
| ? | 01010-81235 | • • BOLT | 12 | SN: (1001-1076) |
|||
| ? | 01643-31232 | • • WASHER | 12 | SN: (1001-1076) |
|||
| ? | 425-32-22670 | • • DISC | 7 | SN: (1001-1076) |
|||
| ? | 56B-15-17730 | • • PLATE,SEPARATE | 7 | SN: (1001-1076) |
|||
| ? | 425-32-22680 | • • PLATE | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-17710 | • • SPRING,WAVE | 7 | SN: (1001-1076) |
|||
| ? | 56B-15-17271 | • • HUB | 1 | SN: (1001-1076) |
|||
| ? | 04064-07525 | • • RING | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-17760 | • • PISTON | 1 | SN: (1001-1076) |
|||
| ? | 287-15-19210 | • • RING,SEAL (K1) | 1 | SN: (1001-1076) |
|||
| ? | 154-15-22831 | • • RING,SEAL (K1) | 1 | SN: (1001-1076) |
|||
| ? | 421-22-12840 | • • BEARING | 2 | SN: (1001-1076) |
|||
| ? | 56B-15-19620 | • • BEARING | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-19321 | • • BEARING | 1 | SN: (0005)-0001076) |
|||
| ? | 56B-15-19320 | • • BEARING | 1 | SN: (1001-(0004) |
|||
| ? | 04065-06220 | • • RING | 1 | SN: (0005)-0001076) |
|||
| ? | 04067-00150 | • • RING | 1 | SN: (1001-(0004) |
|||
| ? | 56B-15-17860 | • • RING,SEAL (K1) | 2 | SN: (1001-1076) |
