| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (56B-13-10002) | TORQFLOW ASS'Y | 1 | SN: (100063)-0001076) |
|||
| ? | (56B-13-10001) | TORQFLOW ASS'Y | 1 | SN: (0005)-(100062) |
|||
| ? | (56B-13-10000) | TORQFLOW ASS'Y | 1 | SN: (1001-(0004) |
|||
| ? | THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 56B-15-14112 | • COUPLING | 1 | SN: (0052)-0001076) |
|||
| ? | □56B-15-14111 | • COUPLING | 1 | SN: (1001-(0051) |
|||
| ? | ☆ | • • COUPLING | 1 | SN: (0052)-0001076) |
|||
| ? | ☆ | • • COUPLING | 1 | SN: (1001-(0051) |
|||
| ? | ☆ | • • COVER | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-19110 | • SEAL,DUST (K1) | 1 | SN: (1001-1076) |
|||
| ? | 07012-50120 | • SEAL,OIL (K1) | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-13261 | • HOLDER | 1 | SN: (0052)-0001076) |
|||
| ? | 56B-15-13260 | • HOLDER | 1 | SN: (1001-(0051) |
|||
| ? | 01051-52420 | • BOLT | 1 | SN: (1001-1076) |
|||
| ? | 01643-32460 | • WASHER | 1 | SN: (1001-1076) |
|||
| ? | 07000-75090 | • O-RING (K1) | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-17121 | • CAGE | 1 | SN: (1001-1076) |
|||
| ? | 01010-81235 | • BOLT | 6 | SN: (1001-1076) |
|||
| ? | 01643-31232 | • WASHER | 6 | SN: (1001-1076) |
|||
| ? | 712-86-12220 | • SHIM¤ 0.50MM (K1) | 8 | SN: (1001-1076) |
|||
| ? | 712-86-12230 | • SHIM¤ 0.20MM (K1) | 4 | SN: (1001-1076) |
|||
| ? | 712-86-12240 | • SHIM¤ 0.15MM (K1) | 4 | SN: (1001-1076) |
|||
| ? | 07000-75240 | • O-RING (K1) | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-12140 | • SLEEVE | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-17111 | • CAGE | 1 | SN: (1001-1076) |
|||
| ? | 07043-70211 | • PLUG | 3 | SN: (1001-1076) |
|||
| ? | 01252-70860 | • BOLT | 4 | SN: (1001-1076) |
|||
| ? | 01641-20812 | • WASHER | 4 | SN: (1001-1076) |
|||
| ? | 01010-81235 | • BOLT | 10 | SN: (1001-1076) |
|||
| ? | 01643-31232 | • WASHER | 10 | SN: (1001-1076) |
|||
| ? | 07000-75230 | • O-RING (K1) | 1 | SN: (1001-1076) |
|||
| ? | 07000-75155 | • O-RING (K1) | 1 | SN: (1001-1076) |
