| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (56B-13-10002) | TORQFLOW ASS'Y | 1 | SN: (100063)-0001076) |
|||
| ? | (56B-13-10001) | TORQFLOW ASS'Y | 1 | SN: (0005)-(100062) |
|||
| ? | (56B-13-10000) | TORQFLOW ASS'Y | 1 | SN: (1001-(0004) |
|||
| ? | THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 56B-13-19860 | • COUPLING ASS'Y | 1 | SN: (1001-1076) |
|||
| ? | ☆ | • • COUPLING | 1 | SN: (1001-1076) |
|||
| ? | ☆ | • • COVER | 1 | SN: (1001-1076) |
|||
| ? | 566-13-42140 | • RETAINER | 1 | SN: (1001-1076) |
|||
| ? | 425-15-28710 | • SEAL,DUST (K1) | 1 | SN: (1001-1076) |
|||
| ? | 07012-50095 | • SEAL,OIL (K1) | 1 | SN: (1001-1076) |
|||
| ? | 07000-72145 | • O-RING (K1) | 1 | SN: (1001-1076) |
|||
| ? | 06031-00314 | • BEARING | 1 | SN: (1001-1076) |
|||
| ? | 711-20-31370 | • HOLDER | 1 | SN: (1001-1076) |
|||
| ? | 07000-75060 | • O-RING (K1) | 1 | SN: (1001-1076) |
|||
| ? | 01010-61675 | • BOLT | 1 | SN: (1001-1076) |
|||
| ? | 01643-31645 | • WASHER | 1 | SN: (1001-1076) |
|||
| ? | 07372-21030 | • BOLT | 2 | SN: (1001-1076) |
|||
| ? | 01641-21016 | • WASHER | 2 | SN: (1001-1076) |
