| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (56B-13-10006) | TORQFLOW ASS'Y | 1 | SN: 1001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 56B-15-12033 | • CLUTCH ASS'Y,2ND AND 3RD | 1 | SN: 1001- |
|||
| ? | 56B-15-12134 | • • SHAFT AND CYLINDER A,2ND AND 3RD | 1 | SN: 1001- |
|||
| ? | ☆ | • • • SHAFT,LOWER | 1 | SN: (100319)- |
|||
| ? | ☆ | • • • SHAFT,LOWER | 1 | SN: 1001-(100318) |
|||
| ? | ☆ | • • • BALL | 2 | SN: 1001- |
|||
| ? | ☆ | • • • HOUSING,2ND AND 3RD | 1 | SN: 1001- |
|||
| ? | 56B-15-12650 | • • PISTON | 1 | SN: 1001- |
|||
| ? | 56B-15-12660 | • • PISTON | 1 | SN: 1001- |
|||
| ? | 714-07-12670 | • • DISC | 20 | SN: 1001- |
|||
| ? | 714-07-12680 | • • PLATE,SEPARATE | 22 | SN: 1001- |
|||
| ? | 714-07-12781 | • • SPRING,WAVE | 20 | SN: 1001- |
|||
| ? | 714-07-12711 | • • PLATE,END | 2 | SN: 1001- |
|||
| ? | 714-07-12720 | • • RING,SNAP | 2 | SN: 1001- |
|||
| ? | 714-16-19210 | • • RING,SEAL (K1) | 2 | SN: 1001- |
|||
| ? | 714-07-12740 | • • RING,SEAL (K1) | 1 | SN: 1001- |
|||
| ? | 56B-15-19210 | • • RING,SEAL (K1) | 1 | SN: 1001- |
|||
| ? | 56B-15-19530 | • • WASHER,THRUST | 1 | SN: 1001- |
|||
| ? | 56B-15-19520 | • • WASHER,THRUST | 3 | SN: 1001- |
|||
| ? | 56B-15-19411 | • • BEARING,NEEDLE | 1 | SN: 1001- |
|||
| ? | 56B-15-19422 | • • BEARING,NEEDLE | 1 | SN: 1001- |
|||
| ? | 56B-15-12942 | • • SPACER | 1 | SN: 1001- |
|||
| ? | 56B-15-12462 | • • GEAR,3RD | 1 | SN: 1001- |
|||
| ? | 56B-15-12451 | • • GEAR,2ND | 1 | SN: 1001- |
|||
| ? | 56B-15-12552 | • • GEAR | 1 | SN: 1001- |
|||
| ? | 56B-15-12960 | • • SPACER,SEAL | 1 | SN: 1001- |
|||
| ? | 04066-00075 | • • RING | 1 | SN: 1001- |
|||
| ? | 56B-15-19311 | • • BEARING | 2 | SN: 1001- |
|||
| ? | 56B-15-12971 | • • SPACER | 1 | SN: 1001- |
|||
| ? | 56B-15-12980 | • • SPACER | 1 | SN: 1001- |
|||
| ? | 56D-15-19230 | • RING,SEAL (K1) | 3 | SN: 1001- |
