| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (56B-13-10002) | TORQFLOW ASS'Y | 1 | SN: (100063)-0001076) |
|||
| ? | (56B-13-10001) | TORQFLOW ASS'Y | 1 | SN: (0005)-(100062) |
|||
| ? | (56B-13-10000) | TORQFLOW ASS'Y | 1 | SN: (1001-(0004) |
|||
| ? | THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 56B-15-12021 | • CLUTCH ASS'Y,FOWARD HI AND 1ST | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-12121 | • • SHAFT AND CYLINDER A,FOWARD HI AND 1ST | 1 | SN: (1001-1076) |
|||
| ? | ☆ | • • • SHAFT,UPPER | 1 | SN: (1001-1076) |
|||
| ? | ☆ | • • • BALL | 2 | SN: (1001-1076) |
|||
| ? | ☆ | • • • HOUSING,FOWARD HI AND 1ST | 1 | SN: .-1076) |
|||
| ? | ☆ | • • • HOUSING,FOWARD HI AND 1ST | 1 | SN: (1001-. |
|||
| ? | 56B-15-12660 | • • PISTON | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-12640 | • • PISTON,1ST | 1 | SN: (1001-1076) |
|||
| ? | 714-07-12670 | • • DISC | 20 | SN: (1001-1076) |
|||
| ? | 714-07-12680 | • • PLATE,SEPARATE | 22 | SN: (1001-1076) |
|||
| ? | 714-07-12780 | • • SPRING,WAVE | 20 | SN: (1001-1076) |
|||
| ? | 714-07-12711 | • • PLATE,END | 2 | SN: (1001-1076) |
|||
| ? | 714-07-12720 | • • RING,SNAP | 2 | SN: (1001-1076) |
|||
| ? | 714-16-19210 | • • RING,SEAL (K1) | 2 | SN: (1001-1076) |
|||
| ? | 56B-15-19210 | • • RING,SEAL (K1) | 1 | SN: (1001-1076) |
|||
| ? | 561-15-59210 | • • RING,SEAL (K1) | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-19530 | • • WASHER,THRUST | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-19520 | • • WASHER,THRUST | 3 | SN: (1001-1076) |
|||
| ? | 714-07-12930 | • • WASHER,THRUST | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-19410 | • • BEARING,NEEDLE | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-19420 | • • BEARING,NEEDLE | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-12930 | • • SPACER | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-12431 | • • GEAR,FOWARD HI | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-12441 | • • GEAR,1ST | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-12540 | • • GEAR,UPPER | 1 | SN: (1001-1076) |
|||
| ? | 56B-15-19540 | • • RING,SNAP | 1 | SN: (0005)-0001076) |
|||
| ? | 04066-00085 | • • SNAP RING | 1 | SN: (1001-(0004) |
|||
| ? | 714-07-19340 | • • BEARING,ROLLER | 2 | SN: (1001-1076) |
|||
| ? | 56D-15-19230 | • RING,SEAL (K1) | 3 | SN: (1001-1076) |
