| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (56B-13-10002) | TORQFLOW ASS'Y | 1 | SN: (100063)-0001076) |
|||
| ? | (56B-13-10001) | TORQFLOW ASS'Y | 1 | SN: (0005)-(100062) |
|||
| ? | (56B-13-10000) | TORQFLOW ASS'Y | 1 | SN: (1001-(0004) |
|||
| ? | THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS. | ||||||
| ? | 566-13-43150 | • CASE | 1 | SN: (1001-1076) |
|||
| ? | 566-13-43140 | • O-RING (K1) | 1 | SN: (0005)-0001076) |
|||
| ? | 281-13-23340 | • O-RING (K1) | 1 | SN: (1001-(0004) |
|||
| ? | 56B-13-14210 | • GEAR | 2 | SN: (1001-1076) |
|||
| ? | 711-35-14230 | • BEARING | 2 | SN: (1001-1076) |
|||
| ? | 711-35-14120 | • PLATE | 2 | SN: (1001-1076) |
|||
| ? | 04065-09530 | • RING | 2 | SN: (1001-1076) |
|||
| ? | 01530-04812 | • NUT | 2 | SN: (1001-1076) |
|||
| ? | 01010-81235 | • BOLT | 14 | SN: (1001-1076) |
|||
| ? | 01010-81245 | • BOLT | 2 | SN: (1001-1076) |
|||
| ? | 01643-31232 | • WASHER | 16 | SN: (1001-1076) |
|||
| ? | 56B-13-14210 | • GEAR | 1 | SN: (1001-1076) |
|||
| ? | 711-35-14230 | • BEARING | 1 | SN: (1001-1076) |
|||
| ? | 711-35-14120 | • PLATE | 1 | SN: (1001-1076) |
|||
| ? | 04065-09530 | • RING | 1 | SN: (1001-1076) |
|||
| ? | 01530-04812 | • NUT | 1 | SN: (1001-1076) |
