| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 381-986968-2 | FRAME,FRONT | 1 | SN: 2325-3080 |
|||
| ? | □381-986968-1 | FRAME,FRONT | 1 | SN: 2325-2582 |
|||
| ? | 385-10001391 | • SHAFT | 1 | SN: 2325-@ |
|||
| ? | 385-10101401 | • SLEEVE | 1 | SN: 2325-@ |
|||
| ? | 381-987897-1 | LADDER,R.H. | 1 | SN: 2325-3080 |
|||
| ? | 381-987896-1 | LADDER,L.H. | 1 | SN: 2325-3080 |
|||
| ? | 381-975865-1 | SUPPORT | 2 | SN: 1399-3080 |
|||
| ? | 380-S1816-00 | SCREW | 4 | SN: 1375-3080 |
|||
| ? | 380-WF18-000 | WASHER | 4 | SN: 3-3080 |
|||
| ? | 380-S1812-00 | BOLT | 2 | SN: 3-3080 |
|||
| ? | 380-E18-0000 | NUT | 6 | SN: 3-3080 |
|||
| ? | 381-986401-2 | RAIL,L.H. | 1 | SN: 2325-3080 |
|||
| ? | 381-986402-2 | RAIL,R.H. | 1 | SN: 2325-3080 |
|||
| ? | 380-S11010-0 | BOLT | 2 | SN: 3-2462 |
|||
| ? | 380-S11016-0 | SCREW | 2 | SN: 2463-3080 |
|||
| ? | 380-S11010-0 | BOLT | 2 | SN: 2463-3080 |
|||
| ? | 384-0131140 | WASHER | 4 | SN: .-@ |
|||
| ? | □380-WL110-00 | WASHER | 4 | SN: 3-. |
|||
| ? | 380-S116268 | SCREW | 8 | SN: 3-@ |
|||
| ? | 380-209134-1 | NUT | 8 | SN: 3-@ |
|||
| ? | 380-S1814-00 | BOLT | 2 | SN: 3-3080 |
|||
| ? | 380-S1816-00 | SCREW | 2 | SN: 3-3080 |
|||
| ? | 380-E18-0000 | NUT | 4 | SN: 3-3080 |
|||
| ? | 380-885277-2 | PLATE ? NAME | 1 | SN: 3-@ |
|||
| ? | 385-10259501 | SCREW | 4 | SN: .-@ |
|||
| ? | □04418-02550 | SCREW | 4 | SN: 3-. |
|||
| ? | 380-885269-1 | PLATE ? CAUTION,TORQUE CONVERTER OIL TEMP. | 1 | SN: 3-@ |
|||
| ? | 381-987323-1 | PLATE,BRAKE PAD | 1 | SN: 2325-@ |
|||
| ? | 381-971351-1 | GROMMET | 1 | SN: 955-@ |
|||
| ? | 381-981766-1 | COVER ASS'Y,R.H. | 1 | SN: 1785-@ |
|||
| ? | 381-981768-1 | COVER ASS'Y,L.H. | 1 | SN: 1785-@ |
|||
| ? | 380-887877-2 | • LATCH | 1 | SN: 1785-@ |
|||
| ? | 04400-00310 | • RIVET | 4 | SN: 2325-@ |
|||
| ? | 381-982515-1 | • RUBBER | 2 | SN: 2325-@ |
|||
| ? | 380-S287-000 | BOLT | 4 | SN: 1785-@ |
|||
| ? | 384-0131101 | WASHER | 4 | SN: .-@ |
|||
| ? | □380-WL18-000 | WASHER | 4 | SN: 1785-. |
|||
| ? | 380-WF110-00 | WASHER | 2 | SN: 2325-@ |
|||
| ? | 380-886302-3 | DECAL | 1 | SN: 3-@ |
