| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 381-985265-2 | TUBE | 1 | SN: .- |
|||
| ? | □381-985265-1 | TUBE | 1 | SN: 2331-. |
|||
| ? | 381-975626-1 | TUBE | 1 | SN: 2325-2330 |
|||
| ? | 382-279025-1 | CLAMP | 4 | SN: 2325- |
|||
| ? | 385-10051551 | TUBE,R.H. | 1 | SN: 3081- |
|||
| ? | 381-986083-1 | CLIP,R.H. | 1 | SN: 2325-3080 |
|||
| ? | 381-299404-1 | CLIP | 3 | SN: 2547- |
|||
| ? | □380-HL3550-0 | CLIP | 3 | SN: 2325-2546 |
|||
| ? | 380-S265-000 | SCREW | 3 | SN: 2325- |
|||
| ? | 384-0131099 | WASHER | 3 | SN: .- |
|||
| ? | □380-WL16-000 | WASHER | 3 | SN: 2325-. |
|||
| ? | 385-10004991 | HOSE | 1 | SN: 2834- |
|||
| ? | □381-970088-1 | PLUG | 1 | SN: 2325-2833 |
|||
| ? | 382-025493-1 | BOLT | 2 | SN: ..- |
|||
| ? | □380-S258-000 | SCREW | 1 | SN: .-.. |
|||
| ? | □380-S258-000 | SCREW | 2 | SN: 2331-. |
|||
| ? | 380-S245-000 | BOLT | 2 | SN: 2325-2330 |
|||
| ? | 384-0120638 | WASHER | 2 | SN: ..- |
|||
| ? | □380-WL15-000 | WASHER | 1 | SN: .-.. |
|||
| ? | □380-WL15-000 | WASHER | 2 | SN: 2331-. |
|||
| ? | 380-WL14-000 | WASHER | 2 | SN: 2325-2330 |
|||
| ? | 382-025520-1 | NUT | 2 | SN: ..- |
|||
| ? | □380-H25-0000 | NUT | 1 | SN: .-.. |
|||
| ? | □380-H25-0000 | NUT | 2 | SN: 2331-. |
|||
| ? | 380-H24-0000 | NUT | 2 | SN: 2325-2330 |
|||
| ? | 381-980316-3 | RESERVOIR | 1 | SN: .- |
|||
| ? | □381-980316-2 | RESERVOIR | 1 | SN: 2667-. |
|||
| ? | □381-980316-1 | RESERVOIR | 1 | SN: 2331-2666 |
|||
| ? | 381-897729-1 | RESERVOIR | 1 | SN: 2325-2330 |
|||
| ? | (381-987815-3) | POWER CLUSTER ASS'Y,(SEE FIG.1365) | 1 | SN: ..- |
|||
| ? | □381-987815-2 | POWER CLUSTER ASS'Y,(SEE FIG.1365) | 1 | SN: .-.. |
|||
| ? | □381-987815-1 | POWER CLUSTER ASS'Y,(SEE FIG.1365) | 1 | SN: 2331-. |
|||
| ? | (381-897728-5) | POWER CLUSTER ASS'Y,(SEE FIG.1365) | 1 | SN: 2325-2330 |
|||
| ? | 380-S168-000 | BOLT | 4 | SN: 213- |
|||
| ? | 384-0131099 | WASHER | 4 | SN: .- |
|||
| ? | □380-WL16-000 | WASHER | 4 | SN: 213-. |
|||
| ? | 380-H16-0000 | NUT | 4 | SN: 213- |
|||
| ? | 380-133049-1 | CONNECTOR | 1 | SN: 1424- |
|||
| ? | 385-10121421 | TUBE | 1 | SN: 3126- |
|||
| ? | □380-189680-1 | TUBE | 1 | SN: 3-3125 |
|||
| ? | 381-975191-1 | TEE | 1 | SN: 1279- |
|||
| ? | 380-HL3753-0 | GASKET | 1 | SN: 1279- |
|||
| ? | 380-HL3553-0 | NIPPLE | 1 | SN: 1279- |
|||
| ? | 385-10000972 | TUBE | 1 | SN: 3081- |
|||
| ? | 381-975195-1 | TUBE | 1 | SN: 1279-3080 |
|||
| ? | 381-299402-1 | CLIP | 1 | SN: 3081- |
|||
| ? | 380-156609-1 | CLIP | 1 | SN: 213-3080 |
|||
| ? | 381-299402-1 | CLIP | 1 | SN: 3081- |
|||
| ? | 380-890414-1 | CLAMP | 1 | SN: 1399-3080 |
|||
| ? | 382-024839-1 | BOLT | 2 | SN: .- |
|||
| ? | □380-S266-000 | BOLT | 2 | SN: 3081-. |
|||
| ? | 380-S157-000 | SCREW | 1 | SN: 1399-3080 |
|||
| ? | 380-WF15-000 | WASHER | 1 | SN: 1399-3080 |
|||
| ? | 384-0131099 | WASHER | 1 | SN: .- |
|||
| ? | □380-WL16-000 | WASHER | 1 | SN: 3081-. |
|||
| ? | 380-WL15-000 | WASHER | 1 | SN: 1399-3080 |
|||
| ? | 380-H15-0000 | NUT | 1 | SN: 1399-3080 |
|||
| ? | 380-146966-1 | TEE | 1 | SN: 3- |
|||
| ? | 380-136271-1 | CLIP | 1 | SN: 3- |
|||
| ? | 380-S147-000 | BOLT | 1 | SN: 3- |
|||
| ? | 384-0131098 | WASHER | 1 | SN: .- |
|||
| ? | □380-WL14-000 | WASHER | 1 | SN: 3-. |
|||
| ? | 380-H14-0000 | NUT | 1 | SN: 3- |
|||
| ? | 381-299400-1 | CLAMP | 2 | SN: 2547- |
|||
| ? | □380-177748-1 | CLAMP | 2 | SN: 3-2546 |
|||
| ? | 380-S1612-00 | BOLT | 2 | SN: 3- |
|||
| ? | 384-0131099 | WASHER | 2 | SN: .- |
|||
| ? | □380-WL16-000 | WASHER | 2 | SN: 3-. |
|||
| ? | 380-H16-0000 | NUT | 2 | SN: 3- |
|||
| ? | 380-177748-1 | CLAMP | 2 | SN: 763- |
|||
| ? | 381-897721-1 | PLATE | 2 | SN: 763- |
|||
| ? | 380-S144-000 | BOLT | 4 | SN: 763- |
|||
| ? | 384-0131098 | WASHER | 4 | SN: .- |
|||
| ? | □380-WL14-000 | WASHER | 4 | SN: 763-. |
|||
| ? | 381-985057-1 | TUBE,R.H. | 1 | SN: 2325- |
|||
| ? | 381-971930-3 | BOLT | 2 | SN: 1183- |
|||
| ? | 380-HA883-00 | GASKET | 2 | SN: 1063- |
|||
| ? | 381-970671-1 | CONNECTOR | 2 | SN: 1183- |
|||
| ? | 381-971931-1 | GASKET | 2 | SN: 1063- |
|||
| ? | 381-985058-1 | TUBE,L.H. | 1 | SN: 2325- |
|||
| ? | 385-10014772 | TUBE | 1 | SN: 3126- |
|||
| ? | □385-10014771 | TUBE | 1 | SN: 3081-3125 |
|||
| ? | 381-975626-1 | TUBE | 1 | SN: 2325-3080 |
