| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (381-970485-3) | TRANSMISSION ASS'Y | 1 | SN: 2325- |
|||
| ? | (381-970486-2) | • HOUSING | 1 | SN: 2325- |
|||
| ? | 380-125511-1 | • • TUBE | 1 | SN: 3- |
|||
| ? | 380-125512-1 | • • TUBE | 1 | SN: 3- |
|||
| ? | 380-125513-1 | • • TUBE | 1 | SN: 3- |
|||
| ? | 380-125517-1 | • • TUBE | 1 | SN: 3- |
|||
| ? | 380-125518-1 | • • TUBE | 1 | SN: 3- |
|||
| ? | 380-886865-1 | • • BUSHING | 10 | SN: 1399- |
|||
| ? | 380-OR25-000 | • • O-RING | 10 | SN: 2823- |
|||
| ? | □380-OR58-000 | • • O-RING | 10 | SN: 1399-2822 |
|||
| ? | 380-OR47-000 | • • O-RING | 10 | SN: 1399- |
|||
| ? | 380-OR411-00 | • O-RING | 2 | SN: 1399- |
|||
| ? | 380-143052-1 | • TUBE | 1 | SN: 3- |
|||
| ? | 380-129553-1 | • ADAPTER ASS'Y | 3 | SN: 1399- |
|||
| ? | 380-885347-1 | • • ADAPTER | 1 | SN: 1399- |
|||
| ? | 380-885348-1 | • • SEAL | 1 | SN: 1399- |
|||
| ? | 380-885349-1 | • • NUT | 1 | SN: 1399- |
|||
| ? | 380-152125-1 | • TUBE | 1 | SN: 3- |
|||
| ? | 380-129554-1 | • ELBOW ASS'Y | 1 | SN: 1399- |
|||
| ? | 380-885351-1 | • • ELBOW | 1 | SN: 1399- |
|||
| ? | 380-885348-1 | • • SEAL | 1 | SN: 1399- |
|||
| ? | 380-885349-1 | • • NUT | 1 | SN: 1399- |
|||
| ? | 380-S2610-00 | • BOLT | 3 | SN: 3- |
|||
| ? | 380-WL16-000 | • WASHER | 3 | SN: 2739- |
|||
| ? | □380-125003-1 | • WASHER | 3 | SN: 3-2738 |
|||
| ? | 380-P12-0000 | • PLUG | 1 | SN: 2919- |
|||
| ? | 385-10005061 | • MANIFOLD | 1 | SN: 2919- |
|||
| ? | 381-981758-2 | • MANIFOLD | 1 | SN: 2895-2918 |
|||
| ? | □381-981758-1 | • MANIFOLD | 1 | SN: 1749-2894 |
|||
| ? | 380-S2622-00 | • BOLT | 1 | SN: 1399- |
|||
| ? | 380-125003-1 | • WASHER | 1 | SN: 3- |
|||
| ? | 380-OR36-000 | • O-RING | 1 | SN: 3- |
|||
| ? | 380-220605-1 | • HOSE | 1 | SN: 1399- |
|||
| ? | 380-029112-0 | • ELBOW | 1 | SN: 1399- |
|||
| ? | 380-OR212-00 | • O-RING | 1 | SN: 1399- |
|||
| ? | 381-879059-1 | • HOSE | 1 | SN: 1399- |
|||
| ? | 380-020512-0 | • ADAPTER | 1 | SN: 1399- |
|||
| ? | 380-OR212-00 | • O-RING | 1 | SN: 1399- |
|||
| ? | 380-OR49-000 | • O-RING | 6 | SN: 1399- |
|||
| ? | 380-82636-00 | • BOLT | 3 | SN: 2739- |
|||
| ? | 381-977101-1 | • BOLT | 3 | SN: 1399-2738 |
|||
| ? | 380-WF36-000 | • WASHER | 3 | SN: 1594- |
|||
| ? | 381-976504-2 | • PLUG | 1 | SN: 1399- |
|||
| ? | 380-OR28-000 | • O-RING | 1 | SN: 1399- |
|||
| ? | 381-983402-1 | • VALVE ASS'Y | 1 | SN: 1399- |
|||
| ? | 380-186242-1 | • CYLINDER ASS'Y | 1 | SN: 3- |
|||
| ? | 385-10017941 | • VALVE ASS'Y | 1 | SN: 3063- |
|||
| ? | (□381-927189-1) | • VALVE ASS'Y | 1 | SN: 1399-3062 |
|||
| ? | 385-10017861 | • LOCKTITE ? 262 | A/R | SN: 3- |
