| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 285-35-12540 | TEE | 1 | SN: 1002- |
|||
| ? | 566-35-11541 | BRACKET | 1 | SN: 1002- |
|||
| ? | 01010-50820 | BOLT | 2 | SN: 1002- |
|||
| ? | 01602-20825 | WASHER | 2 | SN: 1002- |
|||
| ? | 568-35-14120 | PLUG | 1 | SN: 1002- |
|||
| ? | 07003-13036 | GASKET | 1 | SN: 1002- |
|||
| ? | 07030-03034 | BREATHER | 1 | SN: 1002- |
|||
| ? | 07003-13036 | GASKET | 1 | SN: 1002- |
|||
| ? | 07822-00413 | TUBE | 1 | SN: 1002- |
|||
| ? | 281-35-19320 | ELBOW | 1 | SN: 1002- |
|||
| ? | 07326-10302 | ADAPTER | 1 | SN: 1002- |
|||
| ? | 566-35-11180 | TANK | 1 | SN: 1002- |
|||
| ? | 01010-50820 | BOLT | 4 | SN: 1002- |
|||
| ? | 01602-20825 | WASHER | 4 | SN: 1002- |
|||
| ? | 07822-00425 | TUBE | 1 | SN: 1002- |
|||
| ? | 285-35-12710 | TEE | 1 | SN: 1002- |
|||
| ? | 07822-00407 | TUBE | 1 | SN: 1002- |
|||
| ? | 285-35-12710 | TEE | 1 | SN: 1002- |
|||
| ? | 07822-00415 | TUBE | 1 | SN: 1002- |
|||
| ? | 281-35-19320 | ELBOW | 1 | SN: 1002- |
|||
| ? | 561-35-31230 | BRACKET | 1 | SN: 1002- |
|||
| ? | 07283-32236 | CLIP | 1 | SN: 1002- |
|||
| ? | 07283-52232 | SEAT | 1 | SN: 1002- |
|||
| ? | 01599-01011 | NUT | 2 | SN: 1002- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 1002- |
|||
| ? | 02011-70627 | BOLT | 2 | SN: 1002- |
|||
| ? | 566-43-11290 | SPRING | 2 | SN: 1002- |
|||
| ? | 566-35-11280 | PLATE | 2 | SN: 1002- |
|||
| ? | 08036-02514 | CLIP | 8 | SN: 1002- |
|||
| ? | 01010-51020 | BOLT | 4 | SN: 1002- |
|||
| ? | 01580-11008 | NUT | 4 | SN: 1002- |
|||
| ? | 01602-21030 | WASHER | 4 | SN: 1002- |
|||
| ? | (566-35-11205) | BRAKE CHAMBER ASS'Y,FRONT | 4 | SN: 1002- |
|||
| ? | 01010-51235 | BOLT | 16 | SN: 1002- |
|||
| ? | 01602-21236 | WASHER | 16 | SN: 1002- |
|||
| ? | 01580-11210 | NUT | 16 | SN: 1002- |
|||
| ? | 07326-10302 | ADAPTER | 4 | SN: 1002- |
|||
| ? | 07042-00211 | PLUG | 4 | SN: 1002- |
|||
| ? | 07113-00313 | HOSE | 2 | SN: 1002- |
|||
| ? | 566-35-14340 | NIPPLE | 2 | SN: 1002- |
|||
| ? | 566-35-14350 | ELBOW | 2 | SN: 1002- |
|||
| ? | 07113-00305 | HOSE | 4 | SN: 1002- |
|||
| ? | 566-35-14340 | NIPPLE | 8 | SN: 1002- |
|||
| ? | 07113-00311 | HOSE | 4 | SN: 1002- |
|||
| ? | 566-35-14340 | NIPPLE | 4 | SN: 1002- |
|||
| ? | 566-35-14350 | ELBOW | 4 | SN: 1002- |
|||
| ? | 07113-00313 | HOSE | 2 | SN: 1002- |
|||
| ? | 566-35-14350 | ELBOW | 4 | SN: 1002- |
|||
| ? | 07822-00415 | TUBE | 2 | SN: 1002- |
|||
| ? | 281-35-19320 | ELBOW | 2 | SN: 1002- |
|||
| ? | 07326-10302 | ADAPTER | 2 | SN: 1002- |
|||
| ? | 08036-03014 | CLIP | 8 | SN: 1002- |
|||
| ? | 01010-51020 | BOLT | 8 | SN: 1002- |
|||
| ? | 01602-21030 | WASHER | 8 | SN: 1002- |
