| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 566-35-11131 | VALVE ASS'Y | 1 | SN: 1000-1000 |
|||
| ? | 566-35-11132 | VALVE ASS'Y | 1 | SN: 1002- |
|||
| ? | ☆ | • BODY | 1 | SN: 1002- |
|||
| ? | 566-35-00010 | • VALVE ASS'Y (KIT) | 1 | SN: 1002- |
|||
| ? | ☆ | • • SEAT | 1 | SN: 1002- |
|||
| ? | ☆ | • • VALVE | 2 | SN: 1002- |
|||
| ? | ☆ | • • STEM | 1 | SN: 1002- |
|||
| ? | ☆ | • • SPRING | 1 | SN: 1002- |
|||
| ? | ☆ | • • GUIDE | 1 | SN: 1002- |
|||
| ? | 566-35-16170 | • O-RING (KIT) | 1 | SN: 1002- |
|||
| ? | 566-35-16180 | • BOLT | 2 | SN: 1002- |
|||
| ? | 566-35-16191 | • WASHER | 2 | SN: 1002- |
|||
| ? | 566-35-16210 | • SPRING | 1 | SN: 1002- |
|||
| ? | 566-35-16220 | • PISTON | 1 | SN: 1002- |
|||
| ? | 566-35-16230 | • O-RING (KIT) | 1 | SN: 1002- |
|||
| ? | ☆ | • COVER | 1 | SN: 1002- |
|||
| ? | 566-35-00020 | • CAM ASS'Y (KIT) | 1 | SN: 1000-1000 |
|||
| ? | 566-35-00021 | • CAM ASS'Y (KIT) | 1 | SN: 1002- |
|||
| ? | ☆ | • • CAM | 1 | SN: 1000-1000 |
|||
| ? | ☆ | • • CAM | 1 | SN: 1002- |
|||
| ? | ☆ | • • CAM | 1 | SN: 1000-1000 |
|||
| ? | ☆ | • • CAM | 1 | SN: 1002- |
|||
| ? | 566-35-16270 | • SPRING | 1 | SN: 1000-1000 |
|||
| ? | 566-35-16271 | • SPRING | 1 | SN: 1002- |
|||
| ? | 566-35-16280 | • GASKET (KIT) | 1 | SN: 1002- |
|||
| ? | 566-35-16290 | • BOLT | 2 | SN: 1002- |
|||
| ? | 566-35-16310 | • RING | 1 | SN: 1002- |
|||
| ? | 566-35-16320 | • WASHER | 1 | SN: 1002- |
|||
| ? | 566-35-16330 | • CLAMP | 1 | SN: 1002- |
|||
| ? | 566-35-16341 | • BOLT | 2 | SN: 1002- |
|||
| ? | 566-35-16350 | • WASHER | 2 | SN: 1002- |
|||
| ? | 566-35-16371 | • HANDLE | 1 | SN: 1002- |
|||
| ? | 566-35-16380 | • O-RING (KIT) | 1 | SN: 1002- |
|||
| ? | 566-35-16391 | • HEAD | 1 | SN: 1002- |
|||
| ? | 566-35-16412 | • PIN | 1 | SN: 1002- |
|||
| ? | 566-35-16420 | • WASHER | 2 | SN: 1002- |
|||
| ? | 566-35-16440 | • SCREW | 1 | SN: 1002- |
|||
| ? | 566-35-16430 | • SPACER | 1 | SN: 1002- |
