| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 07822-00610 | TUBE | 1 | SN: 1002- |
|||
| ? | 07834-00613 | ELBOW | 2 | SN: 1002- |
|||
| ? | 07832-00614 | NUT | 2 | SN: 1002- |
|||
| ? | 07831-00612 | SLEEVE | 2 | SN: 1002- |
|||
| ? | 08036-30814 | CLIP | 7 | SN: 1002- |
|||
| ? | 01010-51016 | BOLT | 7 | SN: 1002- |
|||
| ? | 01602-21030 | WASHER | 7 | SN: 1002- |
|||
| ? | 566-35-11980 | JOINT | 1 | SN: 1002- |
|||
| ? | 568-35-13112 | HOSE | 1 | SN: 1002- |
|||
| ? | 281-35-13120 | NIPPLE | 2 | SN: 1002- |
|||
| ? | 07324-10200 | TEE | 1 | SN: 1002- |
|||
| ? | 07836-00613 | CONNECTOR | 2 | SN: 1002- |
|||
| ? | 07832-00614 | NUT | 2 | SN: 1002- |
|||
| ? | 07831-00612 | SLEEVE | 2 | SN: 1002- |
|||
| ? | 07822-00650 | TUBE | 1 | SN: 1002- |
|||
| ? | 08036-23014 | CLIP | 1 | SN: 1002- |
|||
| ? | 07822-00610 | TUBE | 1 | SN: 1002- |
|||
| ? | 281-41-13480 | TUBE | 1 | SN: 1002- |
|||
| ? | 07834-00613 | ELBOW | 3 | SN: 1002- |
|||
| ? | 07836-00613 | CONNECTOR | 4 | SN: 1002- |
|||
| ? | 07832-00614 | NUT | 6 | SN: 1002- |
|||
| ? | 07831-00612 | SLEEVE | 6 | SN: 1002- |
|||
| ? | 07822-00625 | TUBE | 1 | SN: 1002- |
|||
| ? | 07822-00620 | TUBE | 1 | SN: 1002- |
|||
| ? | 07822-00435 | TUBE | 1 | SN: 1002- |
|||
| ? | 281-35-18250 | TUBE | 2 | SN: 1002- |
|||
| ? | 28036-30614 | CLIP | 2 | SN: 1002- |
|||
| ? | 01010-51016 | BOLT | 2 | SN: 1002- |
|||
| ? | 01602-21030 | WASHER | 2 | SN: 1002- |
|||
| ? | 07042-20211 | PLUG | 2 | SN: 1002- |
|||
| ? | 08034-00519 | BAND | 10 | SN: 1002- |
|||
| ? | 08034-00536 | BAND (OP) | 5 | SN: 1002- |
|||
| ? | 08036-21814 | CLIP | 2 | SN: 1002- |
|||
| ? | 01010-51016 | BOLT | 2 | SN: 1002- |
|||
| ? | 01602-21030 | WASHER | 2 | SN: 1002- |
|||
| ? | 07834-00410 | ELBOW | 1 | SN: 1002- |
|||
| ? | 07832-00410 | NUT | 3 | SN: 1002- |
|||
| ? | 07831-00411 | SLEEVE | 3 | SN: 1002- |
|||
| ? | 07836-00413 | CONNECTOR | 1 | SN: 1002- |
|||
| ? | 07831-00612 | SLEEVE | 2 | SN: 1002- |
|||
| ? | 07832-00614 | NUT | 2 | SN: 1002- |
|||
| ? | 07836-00410 | CONNECTOR | 1 | SN: 1002- |
|||
| ? | 07831-00411 | SLEEVE | 1 | SN: 1002- |
|||
| ? | 07832-00410 | NUT | 1 | SN: 1002- |
|||
| ? | 08036-22514 | CLIP | 2 | SN: 1002- |
|||
| ? | 01571-01016 | SEAT | 6 | SN: 1002- |
