| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (701-37-19003) | VALVE ASS'Y | 1 | SN: 4001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1660-01A0 T0 Y1660-03A0. | ||||||
| ? | (701-32-47002) | • VALVE SUB ASS'Y | 1 | SN: 4001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1660-01A0 AND Y1660-02A0. | ||||||
| ? | 701-32-45220 | • • CASE | 1 | SN: 4001- |
|||
| ? | 701-32-45330 | • • COLLAR | 1 | SN: 4001- |
|||
| ? | 07000-22060 | • • O-RING | 1 | SN: 4001- |
|||
| ? | 07000-23040 | • • O-RING | 1 | SN: 4001- |
|||
| ? | 01010-81235 | • • BOLT | 2 | SN: 4001- |
|||
| ? | 01643-31232 | • • WASHER | 2 | SN: 4001- |
|||
| ? | 01010-51435 | • • BOLT | 2 | SN: 4001- |
|||
| ? | 01643-31445 | • • WASHER | 2 | SN: 4001- |
|||
| ? | 702-13-21620 | • • BEARING | 1 | SN: 4001- |
|||
| ? | 06120-02520 | • • BEARING | 1 | SN: 4001- |
|||
| ? | 07430-11161 | • • SEAL | 1 | SN: 4001- |
|||
| ? | 07016-00256 | • • SEAL | 1 | SN: 4001- |
|||
| ? | 701-51-32170 | • • PLATE | 1 | SN: 4001- |
|||
| ? | 01010-80820 | • • BOLT | 2 | SN: 4001- |
|||
| ? | 01643-30823 | • • WASHER | 2 | SN: 4001- |
|||
| ? | 702-13-61641 | • • LEVER | 1 | SN: 4001- |
|||
| ? | 702-13-21650 | • • SHAFT | 1 | SN: 4001- |
|||
| ? | 04010-00519 | • • KEY | 1 | SN: 4001- |
|||
| ? | 01010-80835 | • • BOLT | 1 | SN: 4001- |
|||
| ? | 01643-30823 | • • WASHER | 1 | SN: 4001- |
|||
| ? | 702-13-61630 | • • COVER | 1 | SN: 4001- |
|||
| ? | 07000-22060 | • • O-RING | 1 | SN: 4001- |
|||
| ? | 01010-80825 | • • BOLT | 4 | SN: 4001- |
|||
| ? | 01643-30823 | • • WASHER | 4 | SN: 4001- |
|||
| ? | 07000-23030 | • • O-RING | 2 | SN: 4001- |
|||
| ? | 701-32-45341 | • • TUBE | 1 | SN: 4001- |
|||
| ? | 07000-22012 | • • O-RING | 4 | SN: 4001- |
|||
| ? | 6631-51-9580 | • • BOLT | 2 | SN: 4001- |
