| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 561-07-61102 | AIR CONDITIONER | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND245420-6500 | • CASE ASS'Y | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND447600-2340 | • EVAPORATOR | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND447500-1030 | • VALVE,EXPANSION | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND446870-2320 | • TUBE | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND116730-0520 | • DAMPER ASS'Y | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND116730-0530 | • DAMPER ASS'Y | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND245420-3911 | • CASE ASS'Y | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND116452-0561 | • CASE,HEATER | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND116410-9680 | • UNIT ASS'Y | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND116427-8540 | • PIPE | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND7052-200600 | • HOSE,WATER | 3 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND949351-0720 | • CLAMP,HOSE | 6 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND113600-9260 | • VALVE ASS'Y,WATER | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND116427-8550 | • PIPE | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND246680-1111 | • CLAMP,PIPING | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND246440-5200 | • WIRING HARNESS | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND7009-040050 | • PIPE,INSULATOR | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND017732-3051 | • LEVER,CONTROL | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND017732-3041 | • LEVER,CONTROL | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND017732-3060 | • LEVER,CONTROL | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND146625-5040 | • BUSHING | 2 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND116662-3780 | • SHAFT | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND246690-2930 | • CLAMP | 2 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND116662-0590 | • SHAFT | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND063700-6580 | • SERVO MOTOR ASS'Y | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND146625-2630 | • BUSHING | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND146668-6710 | • PACKING | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND146984-4750 | • GROMMET | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND146642-7930 | • PLATE | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND7009-010050 | • PIPE,INSULATOR | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND246690-6740 | • CLAMP | 3 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND017773-0140 | • CLIP | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND017773-0180 | • CLIP | 2 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND017660-3490 | • BRACKET | 2 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND146668-2030 | • PACKING | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND116251-9192 | • CASE | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND146638-9460 | • PACKING | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND146622-6880 | • PACKING | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND116340-2361 | • MOTOR ASS'Y | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND116471-7510 | • BRACKET,CASE | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND146810-9062 | • RESISTOR,BLOWER | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
|||
| ? | ND146651-1840 | • PIPE | 1 | SN: 1055-@ KIT-FLAG: _- SERIALNO: 1055-@ |
|||
| ? | ND077500-3620 | • THERMOSTAT,(NOT SHOWN) | 1 | SN: 1055-2047 KIT-FLAG: _- SERIALNO: 1055-2047 |
