| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 7861-92-1600 | SENSOR | 2 | SN: 1055-1999 |
|||
| ? | 07002-12034 | O-RING | 2 | SN: 1055-@ |
|||
| ? | 08053-01510 | CLIP | 2 | SN: 1055-1999 |
|||
| ? | 01010-81016 | BOLT | 2 | SN: 1055-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 1055-@ |
|||
| ? | 7861-92-4520 | SENSOR | 1 | SN: 1001-@ |
|||
| ? | 07002-23634 | O-RING | 1 | SN: 1001-@ |
|||
| ? | 08053-01512 | CLIP | 1 | SN: 1001-@ |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 1055-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 1055-@ |
|||
| ? | 08036-01814 | CLIP | 1 | SN: 1055-1999 |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 1001-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 1001-@ |
|||
| ? | 08036-01814 | CLIP | 2 | SN: 1001-1999 |
|||
| ? | 01010-81220 | BOLT | 2 | SN: 1001-@ |
|||
| ? | 01643-31232 | WASHER | 2 | SN: 1001-@ |
|||
| ? | 08036-01814 | CLIP | 1 | SN: 1055-@ |
|||
| ? | 565-95-18260 | COLLAR | 1 | SN: 1001-@ |
|||
| ? | 01010-81050 | BOLT | 1 | SN: 1055-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 1055-@ |
|||
| ? | 08053-00912 | CLIP | 2 | SN: 1001-1999 |
|||
| ? | 01010-81020 | BOLT | 2 | SN: 1055-1999 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 1055-1999 |
|||
| ? | 565-95-18260 | COLLAR | 1 | SN: 1001-@ |
|||
| ? | 01010-81050 | BOLT | 1 | SN: 1001-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 1001-@ |
|||
| ? | 08053-00912 | CLIP | 1 | SN: 1001-@ |
|||
| ? | 569-06-67750 | CONNECTOR ASS'Y | 1 | SN: 1001-@ |
|||
| ? | 08036-02514 | CLIP | 1 | SN: 1001-1999 |
|||
| ? | 08036-03014 | CLIP | 2 | SN: 1055-@ |
|||
| ? | 08036-02514 | CLIP | 1 | SN: 1055-1999 |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 1001-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 1001-@ |
|||
| ? | 08020-10000 | DIODE | 1 | SN: 1132-1999 |
|||
| ? | □421-06-11970 | DIODE | 1 | SN: 1001-1131 |
|||
| ? | 08034-00414 | BAND | 1 | SN: 1001-@ |
|||
| ? | 08036-01814 | CLIP | 2 | SN: 1055-@ |
|||
| ? | 01010-81020 | BOLT | 2 | SN: 1055-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 1055-@ |
|||
| ? | 08036-01014 | CLIP | 2 | SN: 1055-@ |
|||
| ? | 01010-81020 | BOLT | 2 | SN: 1055-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 1055-@ |
|||
| ? | 285-02-11320 | CLIP | 1 | SN: 1055-@ |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 1055-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 1055-@ |
|||
| ? | 7861-92-1680 | SENSOR | 1 | SN: 1055-@ |
