| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6212-51-5702) | OIL FILTER ASS'Y,FULL FLOW | 1 | SN: 1055-1999 |
|||
| ? | (600-211-1940) | • ALARM ASS'Y | 1 | SN: 1055-1999 |
|||
| ? | (07005-01612) | • GASKET | 1 | SN: 1055-1999 |
|||
| ? | 144-874-7470 | BOSS | 8 | SN: 1055-1999 |
|||
| ? | 01010-81060 | BOLT | 8 | SN: 1055-1999 |
|||
| ? | 01643-31032 | WASHER | 8 | SN: 1055-1999 |
|||
| ? | 566-86-6A412 | WIRING HARNESS | 1 | SN: 1055-1999 |
|||
| ? | 08036-01414 | CLIP | 7 | SN: 1055-1999 |
|||
| ? | 01010-51016 | BOLT | 1 | SN: 1055-1999 |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 1055-1999 |
|||
| ? | 08034-00414 | BAND | 6 | SN: 1055-1999 |
|||
| ? | 08036-01014 | CLIP | 4 | SN: 1055-1999 |
|||
| ? | 08073-00505 | SWITCH | 1 | SN: 1055-1999 |
|||
| ? | 08036-01014 | CLIP | 4 | SN: 1055-1999 |
|||
| ? | 01010-81020 | BOLT | 3 | SN: 1055-1999 |
|||
| ? | 01643-31032 | WASHER | 3 | SN: 1055-1999 |
|||
| ? | 561-43-41390 | SWITCH,THERMO | 1 | SN: 1055-@ |
|||
| ? | 08053-01512 | CLIP | 1 | SN: 1055-1999 |
|||
| ? | (566-60-6B211) | TANK,HYDRAULIC | 1 | SN: 1055-1999 |
|||
| ? | 561-60-61330 | FLANGE | 1 | SN: 1055-1999 |
|||
| ? | 01010-50612 | BOLT | 3 | SN: 1055-1999 |
|||
| ? | 01643-30623 | WASHER | 3 | SN: 1055-1999 |
|||
| ? | 7861-91-4220 | O-RING | 1 | SN: 1055-1999 |
|||
| ? | 566-35-14350 | ELBOW | 3 | SN: 1055-1999 |
|||
| ? | 566-35-14340 | NIPPLE | 4 | SN: 1055-1999 |
|||
| ? | 566-35-14360 | NIPPLE | 1 | SN: 1055-1999 |
|||
| ? | 07102-20305 | HOSE | 4 | SN: 1055-1999 |
|||
| ? | 281-04-15540 | TUBE,SPIRAL | 4 | SN: 1055-1999 |
|||
| ? | 391-62-19240 | CLIP | 2 | SN: 1055-1999 |
|||
| ? | 569-06-62780 | BLOCK | 2 | SN: 1055-@ |
|||
| ? | 07000-32014 | O-RING | 4 | SN: 1055-@ |
|||
| ? | 7861-92-1910 | SENSOR,HYDRAULIC OIL FILTER | 2 | SN: 1055-@ |
|||
| ? | 07002-21623 | O-RING | 2 | SN: 1055-@ |
|||
| ? | 01010-50645 | BOLT | 4 | SN: 1055-@ |
|||
| ? | 01010-50655 | BOLT | 4 | SN: 1055-@ |
|||
| ? | 01643-30623 | WASHER | 8 | SN: 1055-@ |
|||
| ? | 566-06-6A150 | COVER | 1 | SN: 1055-1999 |
|||
| ? | 08053-01512 | CLIP | 2 | SN: 1055-1999 |
|||
| ? | 01010-51020 | BOLT | 2 | SN: 1055-1999 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 1055-1999 |
|||
| ? | 08034-00414 | BAND | 1 | SN: 1055-1999 |
