| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 565-03-11270 | CUSHION | 4 | SN: 1002-1068 |
|||
| ? | 01010-50820 | BOLT | 8 | SN: 1002-@ |
|||
| ? | 01602-20825 | WASHER | 8 | SN: 1002-@ |
|||
| ? | 01580-10806 | NUT | 8 | SN: 1002-@ |
|||
| ? | 08029-05010 | WIRE | 2 | SN: 1002-@ |
|||
| ? | 566-06-12540 | SWITCH,BACK | 1 | SN: 1002-@ |
|||
| ? | 566-06-13990 | DIODE | 1 | SN: 1002-@ |
|||
| ? | 281-06-13911 | SENSOR,120ЯC ? N.O. | 1 | SN: 1002-@ |
|||
| ? | 566-06-13691 | SENSOR,105ЯC ? N.O. | 1 | SN: 1002-1068 |
|||
| ? | 566-06-13670 | SWITCH,REAR BRAKE OIL | 1 | SN: 1002-1068 |
|||
| ? | 01220-40412 | SCREW | 4 | SN: 1002-@ |
|||
| ? | 01601-20410 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 566-06-13830 | SOCKET | 1 | SN: 1002-@ |
|||
| ? | 01220-40330 | SCREW | 1 | SN: 1002-@ |
|||
| ? | 01580-10302 | NUT | 1 | SN: 1002-@ |
|||
| ? | 01601-20307 | WASHER | 1 | SN: 1002-@ |
|||
| ? | 566-06-15212 | TUBE | 1 | SN: 1002-@ |
|||
| ? | 566-06-13870 | SWITCH | 1 | SN: 1002-1058 |
|||
| ? | 565-06-13212 | ADAPTER | 1 | SN: 1002-1020 |
|||
| ? | 198-06-11941 | SENSOR,WATER TEMPERATURE | 2 | SN: 1059-@ |
|||
| ? | 437-06-12430 | SENSOR,WATER TEMPERATURE | 2 | SN: 1021-1058 |
|||
| ? | 566-06-15222 | TUBE | 1 | SN: 1002-1068 |
|||
| ? | 07213-50510 | CONNECTOR | 1 | SN: 1002-@ |
|||
| ? | 566-06-15270 | TUBE | 1 | SN: 1002-@ |
|||
| ? | 568-06-15130 | CABLE | 1 | SN: 1002-@ |
|||
| ? | 08603-00058 | CABLE | 1 | SN: 1002-@ |
|||
| ? | 437-06-12910 | DIODE | 1 | SN: 1002-@ |
|||
| ? | 566-06-16422 | MIRROR | 1 | SN: 1002-@ |
|||
| ? | 568-06-15910 | MIRROR | 2 | SN: 1002-@ |
|||
| ? | 09495-00000 | FIRE EXTINGUISHER | 1 | SN: 1002-@ |
|||
| ? | 01220-40512 | SCREW | 4 | SN: 1002-@ |
|||
| ? | 01601-20513 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 566-17-18710 | RELAY | 1 | SN: 1002-@ |
|||
| ? | 566-17-18720 | SPRING | 1 | SN: 1002-@ |
|||
| ? | 600-824-4930 | SAFETY RELAY A. | 1 | SN: 1026-@ |
|||
| ? | 6684-81-3310 | SAFETY RELAY ASS'Y | 1 | SN: 1002-1025 |
|||
| ? | 01010-50616 | BOLT | 4 | SN: 1002-@ |
|||
| ? | 01602-00619 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 566-06-16411 | ASHTRAY | 1 | SN: 1002-@ |
|||
| ? | 566-06-16510 | BOX | 1 | SN: 1002-@ |
|||
| ? | 01220-30816 | SCREW | 2 | SN: 1002-@ |
|||
| ? | 01580-00806 | NUT | 2 | SN: 1002-@ |
|||
| ? | 01602-00825 | WASHER | 2 | SN: 1002-@ |
|||
| ? | 01641-00812 | WASHER | 2 | SN: 1002-@ |
|||
| ? | 08141-02400 | LAMP | 1 | SN: 1002-@ |
|||
| ? | 01220-30403 | SCREW | 2 | SN: 1002-@ |
|||
| ? | 01601-00410 | WASHER | 2 | SN: 1002-@ |
|||
| ? | 566-06-16222 | ARM | 2 | SN: 1002-@ |
|||
| ? | 566-06-16232 | BLADE | 2 | SN: 1002-@ |
|||
| ? | 566-06-16242 | LINK | 1 | SN: 1002-@ |
|||
| ? | 566-06-16260 | NUT | 2 | SN: 1002-@ |
|||
| ? | 566-06-16213 | MOTOR | 1 | SN: 1002-@ |
|||
| ? | 07323-30100 | ELBOW | 1 | SN: 1002-1068 |
