| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 566-43-13113 | LEVER | 1 | SN: 1021-1068 |
|||
| ? | 566-43-13112 | LEVER | 1 | SN: 1002-1020 |
|||
| ? | 09304-01250 | KNOB | 1 | SN: 1002-@ |
|||
| ? | 01582-11210 | NUT | 1 | SN: 1002-@ |
|||
| ? | 566-43-13171 | BOX,CONSOLE | 1 | SN: 1021- |
|||
| ? | 566-43-13170 | BOX,CONSOLE | 1 | SN: 1002-1020 |
|||
| ? | 566-43-13181 | PLATE | 1 | SN: 1021- |
|||
| ? | 566-43-13180 | PLATE | 1 | SN: 1002-1020 |
|||
| ? | 01220-40816 | SCREW | 4 | SN: 1021- |
|||
| ? | 01220-40816 | SCREW | 6 | SN: 1002-1020 |
|||
| ? | 01010-51020 | BOLT | 4 | SN: 1002-@ |
|||
| ? | 01602-21030 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 566-43-13160 | BOSS | 1 | SN: 1002-1068 |
|||
| ? | 01010-50830 | BOLT | 2 | SN: 1002-@ |
|||
| ? | 01602-20825 | WASHER | 2 | SN: 1002-@ |
|||
| ? | 06120-01612 | BEARING | 2 | SN: 1002-@ |
|||
| ? | 06122-01603 | SEAL | 2 | SN: 1002-@ |
|||
| ? | 566-43-16260 | PIN | 1 | SN: 1002-@ |
|||
| ? | 01010-50816 | BOLT | 1 | SN: 1002-@ |
|||
| ? | 01602-20825 | WASHER | 1 | SN: 1002-@ |
|||
| ? | 281-43-14250 | SPRING | 1 | SN: 1002-@ |
|||
| ? | 281-43-14260 | BOLT | 1 | SN: 1002-1068 |
|||
| ? | 01582-11210 | NUT | 1 | SN: 1002-1068 |
|||
| ? | 566-43-13122 | BRACKET | 1 | SN: 1002-1068 |
|||
| ? | 01010-51020 | BOLT | 2 | SN: 1002-1068 |
|||
| ? | 01010-51025 | BOLT | 2 | SN: 1002-1068 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 1002-1068 |
|||
| ? | 01602-21030 | WASHER | 4 | SN: 1002-1068 |
|||
| ? | 566-43-13141 | SHAFT | 1 | SN: 1002-1068 |
|||
| ? | 06120-02016 | BEARING | 2 | SN: 1002-1068 |
|||
| ? | 06122-02004 | SEAL | 2 | SN: 1002-1068 |
|||
| ? | 01643-32045 | WASHER | 2 | SN: 1002-1068 |
|||
| ? | 04010-00519 | KEY | 2 | SN: 1002-@ |
|||
| ? | 566-43-11190 | PLATE | 1 | SN: 1002-1068 |
|||
| ? | 04240-10205 | LEVER | 1 | SN: 1002-@ |
|||
| ? | 569-43-13150 | ROD | 1 | SN: 1002-@ |
|||
| ? | 04211-21055 | YOKE | 2 | SN: 1002-@ |
|||
| ? | 01582-11008 | NUT | 2 | SN: 1002-@ |
|||
| ? | 04205-11030 | PIN | 2 | SN: 1002-@ |
|||
| ? | 01641-21016 | WASHER | 2 | SN: 1002-@ |
|||
| ? | 04050-13015 | PIN | 2 | SN: 1002-@ |
|||
| ? | 566-43-13260 | GUARD | 1 | SN: 1002-@ |
|||
| ? | 566-43-13221 | BRACKET | 1 | SN: 1002-@ |
|||
| ? | 01010-51025 | BOLT | 4 | SN: 1002-@ |
|||
| ? | 01602-21030 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 566-43-13211 | LEVER | 1 | SN: 1002-@ |
|||
| ? | 06120-01612 | BEARING | 1 | SN: 1002-@ |
|||
| ? | 06122-01603 | SEAL | 2 | SN: 1002-@ |
|||
| ? | 566-43-13231 | PIN | 1 | SN: 1002-@ |
|||
| ? | 01602-20825 | WASHER | 1 | SN: 1002-@ |
|||
| ? | 01010-50816 | BOLT | 1 | SN: 1002-@ |
|||
| ? | 569-43-13240 | ROD | 1 | SN: 1002-@ |
