| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 566-60-18131 | BRACKET | 1 | SN: 1002-@ |
|||
| ? | 566-60-18142 | BRACKET | 1 | SN: 1002-@ |
|||
| ? | 01010-51435 | BOLT | 5 | SN: 1002-@ |
|||
| ? | 01602-21442 | WASHER | 5 | SN: 1002-@ |
|||
| ? | 07378-02071 | FLANGE | 1 | SN: 1002-1068 |
|||
| ? | 07000-22060 | O-RING | 1 | SN: 1002-1068 |
|||
| ? | 01010-51235 | BOLT | 4 | SN: 1002-1068 |
|||
| ? | 01602-21236 | WASHER | 4 | SN: 1002-1068 |
|||
| ? | 569-60-16120 | BRACKET | 1 | SN: 1002-1113 |
|||
| ? | 569-60-16110 | BRACKET | 1 | SN: 1002-@ |
|||
| ? | 01010-51435 | BOLT | 8 | SN: 1002-@ |
|||
| ? | 01602-21442 | WASHER | 8 | SN: 1002-@ |
|||
| ? | 01010-51430 | BOLT | 8 | SN: 1002-@ |
|||
| ? | 01602-21442 | WASHER | 8 | SN: 1002-@ |
|||
| ? | 566-60-18242 | TUBE | 1 | SN: 1069-@ |
|||
| ? | 569-60-16130 | TUBE | 1 | SN: 1002-1068 |
|||
| ? | 07000-13045 | O-RING | 1 | SN: 1069-@ |
|||
| ? | 07000-22085 | O-RING | 1 | SN: 1002-1068 |
|||
| ? | 01010-51645 | BOLT | 4 | SN: 1002-1068 |
|||
| ? | 01010-51260 | BOLT | 2 | SN: 1069-@ |
|||
| ? | 01010-51270 | BOLT | 2 | SN: 1069-@ |
|||
| ? | 01602-21236 | WASHER | 4 | SN: 1069-@ |
|||
| ? | 01602-21648 | WASHER | 4 | SN: 1002-1068 |
|||
| ? | 07332-01200 | COUPLING | 1 | SN: 1069-@ |
|||
| ? | 07332-01000 | COUPLING ASS'Y | 1 | SN: 1002-1068 |
|||
| ? | 07332-51200 | • GASKET | 1 | SN: 1069-@ |
|||
| ? | 07332-51000 | • GASKET | 1 | SN: 1002-1068 |
|||
| ? | 07332-61000 | • CLAMP | 1 | SN: 1002-1068 |
|||
| ? | 07332-61200 | • CLAMP | 1 | SN: 1069-@ |
|||
| ? | 569-60-16141 | TUBE | 1 | SN: 1069-@ |
|||
| ? | 569-60-16140 | TUBE | 1 | SN: 1002-1068 |
|||
| ? | 07000-13048 | O-RING | 1 | SN: 1069-@ |
|||
| ? | 07000-23042 | O-RING | 1 | SN: 1002-1068 |
|||
| ? | 01010-51040 | BOLT | 4 | SN: 1069-@ |
|||
| ? | 01010-51035 | BOLT | 4 | SN: 1002-1068 |
|||
| ? | 01602-21030 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 566-60-16311 | TUBE | 1 | SN: 1002-@ |
|||
| ? | 07000-13022 | O-RING | 1 | SN: 1069-@ |
|||
| ? | □07000-23022 | O-RING | 1 | SN: 1002-1068 |
|||
| ? | 01010-50830 | BOLT | 4 | SN: 1002-@ |
|||
| ? | 01602-20825 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 07332-00400 | COUPLING ASS'Y | 1 | SN: 1002-@ |
|||
| ? | 07332-50400 | • GASKET | 1 | SN: 1002-@ |
|||
| ? | 07332-60400 | • CLAMP | 1 | SN: 1002-@ |
|||
| ? | 566-60-15420 | TUBE | 1 | SN: 1002-@ |
|||
| ? | 07000-13022 | O-RING | 1 | SN: 1069-@ |
|||
| ? | □07000-23022 | O-RING | 1 | SN: 1002-1068 |
|||
| ? | 01010-50830 | BOLT | 4 | SN: 1002-@ |
|||
| ? | 01602-20825 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 569-60-16150 | BRACKET | 1 | SN: 1002-@ |
|||
| ? | 01010-51235 | BOLT | 4 | SN: 1002-@ |
|||
| ? | 01602-21236 | WASHER | 4 | SN: 1002-@ |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 1002-@ |
