| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-30-00130 | TRACK ROLLER ASS'Y,SINGLE FLANGE | 16 | SN: 12001-@ |
|||
| ? | □207-30-00024 | TRACK ROLLER ASS'Y,SINGLE FLANGE | 16 | SN: 12001-14118 |
|||
| ? | 141-30-36360 | • ROLLER,TRACK | 1 | SN: 12001-14118 |
|||
| ? | 207-30-16211 | • SHAFT | 1 | SN: 12001-14118 |
|||
| ? | 07052-21624 | • PLUG | 1 | SN: 12001-14118 |
|||
| ? | 141-30-00592 | • BUSHING ASS'Y | 2 | SN: 12001-14118 |
|||
| ? | ☆ | • • BUSHING | 1 | SN: 12001-14118 |
|||
| ? | ☆ | • • BUSHING | 1 | SN: 12001-14118 |
|||
| ? | 141-30-36310 | • • PIN,SPRING | 2 | SN: 12001-14118 |
|||
| ? | 07000-05105 | • O-RING | 2 | SN: 12001-14118 |
|||
| ? | 01010-31030 | • BOLT | 12 | SN: 12001-14118 |
|||
| ? | 01602-01030 | • WASHER,SPRING | 12 | SN: 12001-14118 |
|||
| ? | 141-30-00616 | • FLOATING SEAL ASS'Y | 2 | SN: 12001-14118 |
|||
| ? | 141-30-00623 | • • SEAL RING ASS'Y | 1 | SN: 12001-14118 |
|||
| ? | ☆ | • • • RING,SEAL | 2 | SN: 12001-14118 |
|||
| ? | 141-30-00630 | • • O-RING ASS'Y | 1 | SN: 12001-14118 |
|||
| ? | ☆ | • • • O-RING | 2 | SN: 12001-14118 |
|||
| ? | 07000-03052 | • O-RING | 2 | SN: 12001-14118 |
|||
| ? | 141-30-36334 | • COLLAR,INNER | 1 | SN: 12001-14118 |
|||
| ? | 141-30-36344 | • COLLAR,OUTER | 1 | SN: 12001-14118 |
|||
| ? | 141-30-36190 | • PIN | 2 | SN: 12001-14118 |
|||
| ? | 141-30-36180 | KEY | 16 | SN: 12001-14118 |
|||
| ? | 01010-51880 | BOLT | 64 | SN: 12178-14118 |
|||
| ? | □207-30-36310 | BOLT | 64 | SN: 12001-12177 |
|||
| ? | 01643-31845 | WASHER | 64 | SN: 12001-14118 |
|||
| ? | 207-30-31180 | PLATE | 32 | SN: 12001-14118 |
