| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 22W-06-12381 | LAMP ASS'Y | 1 | SN: 12001- |
|||
| ? | 22W-06-12170 | • BULB ? 24V | 1 | SN: 12001- |
|||
| ? | 205-06-64430 | HORN,LOW | 1 | SN: 12001- |
|||
| ? | 175-06-39170 | HORN,HIGH | 1 | SN: 12001- |
|||
| ? | 01010-50816 | BOLT | 4 | SN: 12001- |
|||
| ? | 01643-30823 | WASHER | 4 | SN: 12001- |
|||
| ? | 08088-10000 | SWITCH,BATTERY | 1 | SN: 12001- |
|||
| ? | 01010-50816 | BOLT | 2 | SN: 12001- |
|||
| ? | 01643-30823 | WASHER | 2 | SN: 12001- |
|||
| ? | 7861-91-4700 | SENSOR,FUEL | 1 | SN: 12704- |
|||
| ? | □7861-99-4700 | SENSOR,FUEL | 1 | SN: 12001-12703 |
|||
| ? | 07000-02085 | O-RING | 1 | SN: 12001- |
|||
| ? | 01010-51016 | BOLT | 4 | SN: 12704- |
|||
| ? | 01010-51025 | BOLT | 4 | SN: 12001-12703 |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 12001- |
|||
| ? | 7861-91-4520 | SENSOR,HYDRAULIC OIL | 1 | SN: 12756- |
|||
| ? | □7861-99-4520 | SENSOR,HYDRAULIC OIL | 1 | SN: 12001-12755 |
|||
| ? | 07002-13634 | O-RING | 1 | SN: 12239- |
|||
| ? | 07002-23634 | O-RING | 1 | SN: 12001-12238 |
|||
| ? | 07002-13634 | O-RING | 1 | SN: 12239- |
|||
| ? | 07002-23634 | O-RING | 1 | SN: 12001-12238 |
|||
| ? | 7861-99-4520 | SENSOR,RADIATOR | 1 | SN: 12001- |
|||
| ? | 195-06-41820 | CLIP | 1 | SN: 14004- |
|||
| ? | □08036-01814 | CLIP | 1 | SN: 12001-14003 |
|||
| ? | 7861-91-3310 | SENSOR,WATER TEMPERATURE | 1 | SN: 12756- |
|||
| ? | □7861-99-3300 | SENSOR,WATER TEMPERATURE | 1 | SN: 12001-12755 |
|||
| ? | 207-06-31330 | SENSOR,WATER TEMPERATURE (ANALOG) | 1 | SN: 12001- |
|||
| ? | (600-050-2610) | CLIP | 1 | SN: 12001- |
|||
| ? | 01010-50820 | BOLT | 1 | SN: 12001- |
|||
| ? | 01643-30823 | WASHER | 1 | SN: 12001- |
|||
| ? | 08028-15011 | WIRE ? 110MM | 1 | SN: 13021- |
|||
| ? | 08028-15055 | WIRE ? 550MM | 1 | SN: 12266-13020 |
|||
| ? | 08028-15065 | WIRE ? 650MM | 1 | SN: 12001-12265 |
|||
| ? | 01010-51020 | BOLT | 2 | SN: 13021- |
|||
| ? | 01010-51020 | BOLT | 1 | SN: 12001-13020 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 13021- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 12001-13020 |
