| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-03-00022 | RADIATOR ASS'Y | 1 | SN: 14772- |
|||
| ? | 207-03-00021 | RADIATOR ASS'Y | 1 | SN: 12001-14771 |
|||
| ? | 207-03-31112 | • RADIATOR CORE ASS'Y | 1 | SN: 14772- |
|||
| ? | 207-03-31111 | • RADIATOR CORE ASS'Y | 1 | SN: 12001-14771 |
|||
| ? | 101-03-13141 | • CAP | 1 | SN: 12001- |
|||
| ? | 207-03-31170 | FRAME | 1 | SN: 12001- |
|||
| ? | 207-03-31290 | • SHEET | 1 | SN: 12001- |
|||
| ? | 207-03-31280 | • SHEET | 1 | SN: 12001- |
|||
| ? | 207-03-31180 | SEAT | 1 | SN: 12001- |
|||
| ? | 281-03-11150 | CLAMP | 2 | SN: 12001- |
|||
| ? | 281-03-11160 | SEAT | 2 | SN: 12001- |
|||
| ? | 01010-51020 | BOLT | 8 | SN: 12001- |
|||
| ? | 01643-51032 | WASHER | 8 | SN: 12001- |
|||
| ? | 281-03-11170 | SHIM ? 0.6MM | 16 | SN: 12001- |
|||
| ? | 207-03-31210 | OIL COOLER ASS'Y | 1 | SN: 12001- |
|||
| ? | 01010-51635 | BOLT | 4 | SN: 12001- |
|||
| ? | 01643-31645 | WASHER | 4 | SN: 12001- |
|||
| ? | 207-03-31330 | SHROUD,UPPER | 1 | SN: 14095- |
|||
| ? | 207-03-31230 | SHROUD,UPPER | 1 | SN: 12001-14094 |
|||
| ? | 207-03-31340 | SHROUD,LOWER | 1 | SN: 14095- |
|||
| ? | 207-03-31240 | SHROUD,LOWER | 1 | SN: 12001-14094 |
|||
| ? | 01010-51016 | BOLT | 13 | SN: 12001- |
|||
| ? | 01643-31032 | WASHER | 13 | SN: 12001- |
|||
| ? | 207-03-31251 | NET | 1 | SN: 12001- |
|||
| ? | 01010-51025 | BOLT | 3 | SN: 12001- |
|||
| ? | 01643-31032 | WASHER | 3 | SN: 12001- |
|||
| ? | 207-03-12160 | PIPE | 1 | SN: 12001- |
|||
| ? | 08034-00536 | BAND | 1 | SN: 13021- |
|||
| ? | 07283-24949 | CLIP | 1 | SN: 12001- |
|||
| ? | 01599-01011 | NUT | 2 | SN: 12001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 12001- |
|||
| ? | 01010-51640 | BOLT | 4 | SN: 12001- |
|||
| ? | 01643-31645 | WASHER | 4 | SN: 12001- |
|||
| ? | 207-03-31191 | STAY | 2 | SN: 12001- |
|||
| ? | 01010-51630 | BOLT | 4 | SN: 12001- |
|||
| ? | 01643-31645 | WASHER | 4 | SN: 12001- |
