| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 22U-03-22510 | BRACKET | 1 | SN: 30001- |
|||
| ? | 01010-81025 | BOLT | 2 | SN: 30001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 30001- |
|||
| ? | 22U-03-22440 | BRACKET | 1 | SN: 30001- |
|||
| ? | 01010-81020 | BOLT | 2 | SN: 30001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 30001- |
|||
| ? | 22U-03-22141 | AFTER COOLER | 1 | SN: 30001- |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 30001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 30001- |
|||
| ? | 22U-03-22860 | CUSHION | 2 | SN: 30001- |
|||
| ? | 6738-61-4952 | COLLAR | 2 | SN: 30001- |
|||
| ? | 22U-979-1740 | CONDENSER ASS'Y | 1 | SN: 30001- |
|||
| ? | 01010-80825 | BOLT | 4 | SN: 30001- |
|||
| ? | 01643-30823 | WASHER | 4 | SN: 30001- |
|||
| ? | 21K-03-71650 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22540 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22570 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22620 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22630 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22640 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22650 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22670 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22690 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22710 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22720 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22730 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22740 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22750 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22760 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22770 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22820 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22830 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22840 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22850 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22430 | SHEET | 1 | SN: 30001- |
|||
| ? | 22U-03-22250 | HOSE | 1 | SN: 30001- |
|||
| ? | 07289-00055 | CLAMP | 2 | SN: 30001- |
|||
| ? | 20Y-62-15960 | CLIP | 1 | SN: 30001- |
|||
| ? | 01010-81225 | BOLT | 1 | SN: 30001- |
|||
| ? | 01643-31232 | WASHER | 1 | SN: 30001- |
|||
| ? | 208-62-38370 | CLIP | 1 | SN: 30001- |
|||
| ? | 22U-03-22260 | HOSE | 1 | SN: 30001- |
|||
| ? | 01010-81030 | BOLT | 1 | SN: 30001- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 30001- |
|||
| ? | 560-43-15220 | WASHER | 1 | SN: 30001- |
|||
| ? | 07289-00055 | CLAMP | 1 | SN: 30001- |
|||
| ? | 07289-00070 | CLAMP | 1 | SN: 30001- |
