| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (☉22U-63-X9330) | CYLINDER GROUP,(NATURAL YELLOW) | 1 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | ==================== | SERIALNO: |
|||||
| ? | 22U-63-02633 | CYLINDER ASS'Y | 1 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 22U-63-72342 | • CYLINDER | 1 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 20Y-70-21230 | • BUSHING | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 07145-00070 | • SEAL,DUST (KIT) | 2 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 205-63-71320 | • ROD,PISTON | 1 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 22U-70-21260 | • BUSHING | 2 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 20Y-70-23220 | • SEAL,DUST (KIT) | 2 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 707-27-11981 | • HEAD,CYLINDER | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 07179-13094 | • RING,SNAP | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 195-63-92190 | • SEAL,DUST (KIT) | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 707-52-90560 | • BUSHING | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 707-51-80030 | • PACKING,ROD (KIT) | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 07000-15105 | • O-RING (KIT) | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 707-35-91150 | • RING,BACK-UP (KIT) | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 707-51-80640 | • RING,BUFFER (KIT) | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 01010-81670 | • BOLT | 12 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 01643-51645 | • WASHER | 12 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 707-36-11661 | • PISTON | 1 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 707-44-11280 | • RING,PISTON (KIT) | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 707-39-11510 | • RING,WEAR (KIT) | 2 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 707-44-11920 | • RING | 2 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 707-35-90360 | • RING,BACK-UP (KIT) | 2 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 07000-15070 | • O-RING (KIT) | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 01310-01216 | • SCREW | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 07020-00000 | • FITTING,GREASE | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 07020-00000 | • FITTING,GREASE | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 205-63-71171 | TUBE | 1 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 01435-01055 | BOLT | 2 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 01435-01040 | BOLT | 2 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 07000-13030 | O-RING (KIT) | 1 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | 22U-63-72390 | BRACKET | 2 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 707-88-21270 | BAND | 2 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 01010-81035 | BOLT | 4 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 01643-51032 | WASHER | 4 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 07282-02793 | CLAMP | 2 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 01010-81020 | BOLT | 4 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 20001-@ KIT-FLAG: _- SERIALNO: 20001-@ |
|||
| ? | ==================== | SERIALNO: |
|||||
| ? | 707-99-45220 | SERVICE KIT | 1 | SN: 20001-21221 KIT-FLAG: _- SERIALNO: 20001-21221 |
