| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (706-7G-01011) | MOTOR ASS'Y | 1 | SN: 20005- |
|||
| ? | (706-7G-01010) | MOTOR ASS'Y | 1 | SN: 20001-20004 |
|||
| ? | 22U-26-21280 | RING | 1 | SN: 20001- |
|||
| ? | 07042-00312 | PLUG | 1 | SN: 20001- |
|||
| ? | 22U-26-21190 | CASE | 1 | SN: 20001- |
|||
| ? | 07029-00000 | VALVE | 1 | SN: 20001- |
|||
| ? | 20Y-26-22330 | BEARING | 1 | SN: 20001- |
|||
| ? | 22U-26-21340 | BEARING | 1 | SN: 20001- |
|||
| ? | 22U-26-21560 | SHAFT ? 15 TEETH | 1 | SN: 20001- |
|||
| ? | 07012-00115 | SEAL | 1 | SN: 20001- |
|||
| ? | 22U-26-21270 | SPACER | 1 | SN: 20001- |
|||
| ? | 07000-15310 | O-RING | 1 | SN: 20001- |
|||
| ? | 22U-26-21580 | CARRIER | 1 | SN: 20001- |
|||
| ? | 22U-26-21540 | GEAR | 4 | SN: 20001- |
|||
| ? | 20G-26-11240 | BEARING | 4 | SN: 20001- |
|||
| ? | 20Y-27-21240 | WASHER | 8 | SN: 20001- |
|||
| ? | 20Y-26-22250 | PIN | 4 | SN: 20001- |
|||
| ? | 20Y-27-21280 | PIN | 4 | SN: 20001- |
|||
| ? | 20Y-26-21240 | PLATE | 1 | SN: 20001- |
|||
| ? | 112-32-11211 | BOLT ? SHOE | 1 | SN: 20001- |
|||
| ? | 22U-26-21551 | GEAR | 1 | SN: 21531- |
|||
| ? | □22U-26-21550 | GEAR | 1 | SN: 20001-21530 |
|||
| ? | 20K-22-11190 | O-RING | 1 | SN: 20001- |
|||
| ? | 01010-81440 | BOLT | 18 | SN: 20854- |
|||
| ? | 01010-81435 | BOLT | 18 | SN: 20001-20853 |
|||
| ? | 01643-31445 | WASHER | 18 | SN: 20854- |
|||
| ? | 22U-26-21530 | GEAR | 1 | SN: 20001- |
|||
| ? | 22U-26-21570 | CARRIER | 1 | SN: 20001- |
|||
| ? | 22U-26-21520 | GEAR | 3 | SN: 20001- |
|||
| ? | 20Y-26-21281 | BEARING | 3 | SN: 20001- |
|||
| ? | 22U-26-21230 | WASHER,THRUST | 6 | SN: 20001- |
|||
| ? | 22U-26-21210 | PIN | 3 | SN: 20001- |
|||
| ? | 04064-03515 | RING | 6 | SN: 20001- |
|||
| ? | 22U-26-21250 | WASHER,THRUST | 1 | SN: 20001- |
|||
| ? | 22U-26-21510 | GEAR | 1 | SN: 20001- |
|||
| ? | 195-03-13241 | VALVE | 1 | SN: 20001- |
|||
| ? | 205-26-71620 | TUBE | 1 | SN: 20001- |
|||
| ? | 07281-00197 | CLAMP | 1 | SN: 20001- |
|||
| ? | 01010-81035 | BOLT | 6 | SN: 20001- |
|||
| ? | 01643-51032 | WASHER | 6 | SN: 20001- |
|||
| ? | 22U-26-21410 | TUBE | 1 | SN: 20001- |
|||
| ? | 22U-26-21420 | FILLER | 1 | SN: 20001- |
|||
| ? | 22U-26-21430 | GAUGE | 1 | SN: 20001- |
|||
| ? | 22U-26-21440 | BRACKET | 1 | SN: 20001- |
|||
| ? | 22U-26-21450 | BRACKET | 1 | SN: 20001- |
|||
| ? | 22U-26-21460 | CAP | 1 | SN: 20001- |
|||
| ? | 07238-10630 | CONNECTOR | 1 | SN: 20001- |
|||
| ? | 07283-32738 | CLIP | 1 | SN: 20001- |
|||
| ? | 04434-51710 | CLIP | 1 | SN: 20001- |
|||
| ? | 01597-01009 | NUT | 2 | SN: 20001- |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 20001- |
|||
| ? | 01010-81025 | BOLT | 3 | SN: 20001- |
|||
| ? | 01643-31032 | WASHER | 7 | SN: 20001- |
|||
| ? | 07000-15240 | O-RING | 1 | SN: 20001- |
|||
| ? | 01010-82060 | BOLT | 12 | SN: 20001- |
|||
| ? | 01643-32060 | WASHER | 12 | SN: 20001- |
