| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-47-20302) | VALVE ASS'Y | 1 | SN: 21290- |
|||
| ? | (723-47-20301) | VALVE ASS'Y | 1 | SN: 20805-21289 |
|||
| ? | (723-47-20300) | VALVE ASS'Y | 1 | SN: 20001-20804 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-21A0 TO Y1662-39A0. | ||||||
| ? | 723-40-66701 | • VALVE ASS'Y | 1 | SN: 20001- |
|||
| ? | ☆ | • • CASE | 1 | SN: 20001- |
|||
| ? | ☆ | • • SEAT | 1 | SN: 20001- |
|||
| ? | ☆ | • • SEAT | 1 | SN: 20001- |
|||
| ? | 708-8H-11530 | • • PLUG | 1 | SN: 20001- |
|||
| ? | 07002-11423 | • • O-RING | 1 | SN: 20001- |
|||
| ? | ☆ | • • SEAT | 2 | SN: 20001- |
|||
| ? | ☆ | • • BALL | 2 | SN: 20001- |
|||
| ? | ☆ | • • PLUG | 1 | SN: 20001- |
|||
| ? | 723-40-66601 | • VALVE ASS'Y | 1 | SN: 20001- |
|||
| ? | ☆ | • • CASE | 1 | SN: 20001- |
|||
| ? | ☆ | • • SEAT | 3 | SN: 20001- |
|||
| ? | ☆ | • • SEAT | 3 | SN: 20001- |
|||
| ? | ☆ | • • BALL | 3 | SN: 20001- |
|||
| ? | ☆ | • • PLUG | 1 | SN: 20001- |
|||
| ? | 01252-61050 | • BOLT | 14 | SN: 20001- |
|||
| ? | 01643-51032 | • WASHER | 14 | SN: 20001- |
|||
| ? | 723-40-60101 | • VALVE ASS'Y | 1 | SN: 20001- |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 20001- |
|||
| ? | ☆ | • • VALVE | 1 | SN: 20001- |
|||
| ? | ☆ | • • PISTON | 1 | SN: 20001- |
|||
| ? | ☆ | • • PISTON | 1 | SN: 20001- |
|||
| ? | ☆ | • • SPRING | 1 | SN: 20001- |
|||
| ? | 07000-12020 | • • O-RING | 1 | SN: 20001- |
|||
| ? | 07001-02020 | • • RING,BACK-UP | 1 | SN: 20001- |
|||
| ? | 709-25-11390 | • • O-RING | 1 | SN: 20001- |
|||
| ? | ☆ | • • SPRING | 1 | SN: 20001- |
|||
| ? | ☆ | • • PLUG | 1 | SN: 20001- |
|||
| ? | ☆ | • • O-RING | 1 | SN: 20001- |
|||
| ? | ☆ | • • SEAL | 1 | SN: 20001- |
|||
| ? | ☆ | • • O-RING | 1 | SN: 20001- |
