| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (22U-60-12510) | MOTOR | 1 | SN: 11001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1641-21A0 TO Y1641-23A0. | ||||||
| ? | TZ684B400002-D | • MOTOR | 1 | SN: 11001- |
|||
| ? | TZ684B410002-D | • • FLANGE ASS'Y | 1 | SN: 11001- |
|||
| ? | TZ684B410102-D | • • • FLANGE KIT | 1 | SN: 11001- |
|||
| ? | ☆ | • • • • FLANGE | 1 | SN: 11001- |
|||
| ? | ☆ | • • • • SPOOL | 1 | SN: 11001- |
|||
| ? | ☆ | • • • • PISTON | 1 | SN: 11001- |
|||
| ? | TZ100A2021-00 | • • • PLUG | 1 | SN: 11001- |
|||
| ? | TZ100A2051-00 | • • • PLUG | 2 | SN: 11001- |
|||
| ? | TZ671B405200-A | • • • STOPPER | 2 | SN: 11001- |
|||
| ? | TZ120F2053-00 | • • • PLUG | 2 | SN: 11001- |
|||
| ? | TZ120F2054-00 | • • • VALVE | 2 | SN: 11001- |
|||
| ? | TZ100A2055-00 | • • • SPRING | 2 | SN: 11001- |
|||
| ? | TZ120F2055-00 | • • • SPRING | 2 | SN: 11001- |
|||
| ? | 07000-13032 | • • • O-RING (K1) | 2 | SN: 11001- |
|||
| ? | 07000-13022 | • • • O-RING (K1) | 2 | SN: 11001- |
|||
| ? | TZ512B2021-00 | • • • PLUG | 2 | SN: 11001- |
|||
| ? | TZGDL-1-16-S | • • • PLUG | 7 | SN: 11001- |
|||
| ? | 07000-12018 | • • • O-RING (K1) | 1 | SN: 11001- |
|||
| ? | TZ610B2021-00 | • • • PLUG | 1 | SN: 11001- |
|||
| ? | 07000-12011 | • • • O-RING (K1) | 2 | SN: 11001- |
|||
| ? | 07000-12014 | • • • O-RING (K1) | 2 | SN: 11001- |
|||
| ? | TZ678B4069-00 | • • • SPOOL | 1 | SN: 11001- |
|||
| ? | TZ678B4089-00 | • • • SPRING | 1 | SN: 11001- |
|||
| ? | 04260-00952 | • • • BALL | 2 | SN: 11001- |
|||
| ? | 07002-12034 | • • • O-RING (K1) | 1 | SN: 11001- |
|||
| ? | TZ263B2079-01 | • • • FILTER | 1 | SN: 11001- |
|||
| ? | TZ810B2021-00 | • • • PLUG | 2 | SN: 11001- |
|||
| ? | TZ682B4082-00 | • • • PLUG | 2 | SN: 11001- |
|||
| ? | 07000-11005 | • • • O-RING (K1) | 2 | SN: 11001- |
|||
| ? | 07000-11008 | • • • O-RING (K1) | 2 | SN: 11001- |
|||
| ? | TZJB1501-7 | • • • BALL | 2 | SN: 11001- |
|||
| ? | TZS0807 | • • • ORIFICE | 1 | SN: 11001- |
|||
| ? | GM-1-8-S | • • • PLUG | 4 | SN: 11001- |
|||
| ? | TZ850A0006-00 | • • • PLATE ? NAME | 1 | SN: 11001- |
|||
| ? | 07042-20108 | • • • PLUG | 2 | SN: 11001- |
|||
| ? | TZJB1354-6-14 | • • • PIN | 1 | SN: 11001- |
|||
| ? | 01252-41640 | • • • BOLT | 12 | SN: 11001- |
|||
| ? | SERVICE KIT | ||||||
| ? | TZ695B9000-00 | SERVICE KIT | 1 | SN: 11001- |
|||
| ? | 07000-11008 | • O-RING | 4 | SN: 11001- |
|||
| ? | 07000-05230 | • O-RING | 1 | SN: 11001- |
|||
| ? | 07000-05335 | • O-RING | 1 | SN: 11001- |
|||
| ? | 207-27-61330 | • RING | 2 | SN: 11001- |
|||
| ? | 07000-12018 | • O-RING | 6 | SN: 11001- |
|||
| ? | TZOS-385811 | • SEAL | 1 | SN: 11001- |
|||
| ? | TZ671B4035-00 | • O-RING | 1 | SN: 11001- |
|||
| ? | TZ671B4039-00 | • O-RING | 1 | SN: 11001- |
|||
| ? | 07000-12016 | • O-RING | 2 | SN: 11001- |
|||
| ? | 07000-12022 | • O-RING | 2 | SN: 11001- |
|||
| ? | 07001-02016 | • RING | 4 | SN: 11001- |
|||
| ? | TZJB2407T2-P22 | • RING | 4 | SN: 11001- |
|||
| ? | 07000-13029 | • O-RING | 2 | SN: 11001- |
|||
| ? | TZSPGO-10H | • SEAL | 2 | SN: 11001- |
|||
| ? | 07000-13032 | • O-RING | 2 | SN: 11001- |
|||
| ? | 07000-13022 | • O-RING | 2 | SN: 11001- |
|||
| ? | 07000-12018 | • O-RING | 1 | SN: 11001- |
|||
| ? | 07000-12011 | • O-RING | 2 | SN: 11001- |
|||
| ? | 07000-12014 | • O-RING | 2 | SN: 11001- |
|||
| ? | 07002-12034 | • O-RING | 1 | SN: 11001- |
|||
| ? | 07000-11005 | • O-RING | 2 | SN: 11001- |
