| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (☉22U-63-X9110) | CYLINDER GROUP,L.H. (NATURAL YELLOW) | 1 | SN: 11673- |
|||
| ? | (☉22U-63-X2302) | CYLINDER GROUP,L.H. (NATURAL YELLOW) | 1 | SN: 11001-11672 |
|||
| ? | (☉22U-63-X9080) | CYLINDER GROUP,L.H. (VIOLET BLUE) | 1 | SN: 11673- |
|||
| ? | (☉22U-63-X2350) | CYLINDER GROUP,L.H. (VIOLET BLUE) | 1 | SN: 11001-11672 |
|||
| ? | (☉22U-63-X9120) | CYLINDER GROUP,R.H. (NATURAL YELLOW) | 1 | SN: 11673- |
|||
| ? | (☉22U-63-X2312) | CYLINDER GROUP,R.H. (NATURAL YELLOW) | 1 | SN: 11001-11672 |
|||
| ? | (☉22U-63-X9090) | CYLINDER GROUP,R.H. (VIOLET BLUE) | 1 | SN: 11673- |
|||
| ? | (☉22U-63-X2360) | CYLINDER GROUP,R.H. (VIOLET BLUE) | 1 | SN: 11001- |
|||
| ? | ==================== | ||||||
| ? | 22U-63-02203 | CYLINDER ASS'Y | 1 | SN: 11001- |
|||
| ? | 22U-63-52342 | • CYLINDER | 1 | SN: 11001- |
|||
| ? | 205-70-71360 | • BUSHING | 1 | SN: 11001- |
|||
| ? | 07145-00070 | • SEAL,DUST (KIT) | 2 | SN: 11001- |
|||
| ? | 22U-63-52323 | • ROD,PISTON | 1 | SN: 11001- |
|||
| ? | 707-76-80010 | • BUSHING | 1 | SN: 11001- |
|||
| ? | 07145-00080 | • SEAL,DUST (KIT) | 2 | SN: 11001- |
|||
| ? | 707-27-12921 | • HEAD,CYLINDER | 1 | SN: 11001- |
|||
| ? | 07179-13099 | • RING,SNAP | 1 | SN: 11001- |
|||
| ? | 707-56-85510 | • SEAL,DUST (KIT) | 1 | SN: 11001- |
|||
| ? | 707-52-90610 | • BUSHING | 1 | SN: 11001- |
|||
| ? | 707-51-85030 | • PACKING,ROD (KIT) | 1 | SN: 11001- |
|||
| ? | 07000-15110 | • O-RING (KIT) | 1 | SN: 11001- |
|||
| ? | 707-35-91220 | • RING,BACK-UP (KIT) | 1 | SN: 11001- |
|||
| ? | 707-51-85630 | • RING,BUFFER (KIT) | 1 | SN: 11001- |
|||
| ? | 01010-81670 | • BOLT | 12 | SN: 11001- |
|||
| ? | 01643-51645 | • WASHER | 12 | SN: 11001- |
|||
| ? | 707-36-12071 | • PISTON | 1 | SN: 11001- |
|||
| ? | 707-44-12180 | • RING,PISTON (KIT) | 1 | SN: 11001- |
|||
| ? | 707-39-12110 | • RING,WEAR (KIT) | 2 | SN: 11001- |
|||
| ? | 707-44-12911 | • RING | 2 | SN: 11001- |
|||
| ? | 07000-15075 | • O-RING (KIT) | 1 | SN: 11001- |
|||
| ? | 707-35-90930 | • RING,BACK-UP (KIT) | 2 | SN: 11001- |
|||
| ? | 01310-01216 | • SCREW | 1 | SN: 11001- |
|||
| ? | 22U-63-52371 | TUBE,L.H. | 1 | SN: 11001- |
|||
| ? | 22U-63-52471 | TUBE,R.H. | 1 | SN: 11001- |
|||
| ? | 22U-63-52380 | TUBE,L.H. | 1 | SN: 11001- |
|||
| ? | 22U-63-52480 | TUBE,R.H. | 1 | SN: 11001- |
|||
| ? | 01435-01055 | BOLT | 4 | SN: 11001- |
|||
| ? | 01435-01040 | BOLT | 4 | SN: 11001- |
|||
| ? | 07000-13030 | O-RING (KIT) | 2 | SN: 11001- |
|||
| ? | 22U-63-52391 | BRACKET,L.H. | 1 | SN: 11001- |
|||
| ? | 22U-63-52491 | BRACKET,R.H. | 1 | SN: 11001- |
|||
| ? | 707-88-96530 | BAND | 1 | SN: 11001- |
|||
| ? | 01010-81035 | BOLT | 2 | SN: 11001- |
|||
| ? | 01643-51032 | WASHER | 2 | SN: 11001- |
|||
| ? | 07283-22738 | CLIP | 2 | SN: 11001- |
|||
| ? | 01599-01011 | NUT | 4 | SN: 11001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 11001- |
|||
| ? | ==================== | ||||||
| ? | 707-98-46220 | SERVICE KIT | 2 | SN: 11001- |
