| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-2L-00413) | PUMP ASS'Y | 1 | SN: 11079- |
|||
| ? | (708-2L-00411) | PUMP ASS'Y | 1 | SN: 11001-11078 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A1 TO Y1600-09A1. | ||||||
| ? | (708-2L-01442) | • PUMP SUB ASS'Y | 1 | SN: 11079- |
|||
| ? | (708-2L-01440) | • PUMP SUB ASS'Y | 1 | SN: 11001-11078 |
|||
| ? | (★04020-01228) | • • PIN | 1 | SN: 11001- |
|||
| ? | (★07000-B1009) | • • O-RING | 1 | SN: 11001- |
|||
| ? | (★01252-61230) | • • BOLT | 4 | SN: 11001- |
|||
| ? | (★708-2L-24513) | • • PISTON,SERVO | 1 | SN: 11001- |
|||
| ? | (★708-2L-24670) | • • SEAL | 1 | SN: 11001- |
|||
| ? | (★708-2L-24570) | • • SLIDER | 1 | SN: 11001- |
|||
| ? | (★708-2L-24560) | • • STOPPER | 1 | SN: 11001- |
|||
| ? | (★07000-B3040) | • • O-RING | 1 | SN: 11001- |
|||
| ? | (★07001-03040) | • • RING,BACK-UP | 1 | SN: 11001- |
|||
| ? | (★708-2L-24522) | • • COVER | 1 | SN: 11001- |
|||
| ? | (★01252-61445) | • • BOLT | 4 | SN: 11001- |
|||
| ? | (★113-43-31380) | • • WASHER | 4 | SN: 11001- |
|||
| ? | (★708-2L-24640) | • • BOLT | 1 | SN: 11001- |
|||
| ? | (★708-2L-24650) | • • NUT | 1 | SN: 11001- |
|||
| ? | (★708-2L-24630) | • • SPRING | 1 | SN: 11001- |
|||
| ? | (★708-2L-24531) | • • SCREW | 1 | SN: 11079- |
|||
| ? | (★708-2L-24530) | • • SCREW | 1 | SN: 11001-11078 |
|||
| ? | (★708-2L-24620) | • • O-RING | 1 | SN: 11001- |
|||
| ? | (★708-2L-24661) | • • WASHER | 1 | SN: 11079- |
|||
| ? | (★708-2L-24660) | • • WASHER | 1 | SN: 11001-11078 |
|||
| ? | (★708-2L-24590) | • • NUT | 1 | SN: 11001- |
