| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6138-12-5512) | MUFFLER,CERAMIC | 1 | SN: 30001-@ |
|||
| ? | (6138-12-5550) | • FILTER | 1 | SN: 30001-@ |
|||
| ? | (6138-12-5521) | • BODY ASS'Y | 1 | SN: 30001-@ |
|||
| ? | (6138-12-5531) | • BODY ASS'Y | 1 | SN: 30001-@ |
|||
| ? | (6138-12-5561) | • GASKET | 2 | SN: 30001-@ |
|||
| ? | (01435-01030) | • BOLT | 18 | SN: 30001-@ |
|||
| ? | (01584-01008) | • NUT | 18 | SN: 30001-@ |
|||
| ? | (07042-20108) | • PLUG | 1 | SN: 30001-@ |
|||
| ? | 20Y-01-21570 | TUBE | 1 | SN: 30001-@ |
|||
| ? | 01580-00806 | NUT | 4 | SN: 30001-30358 |
|||
| ? | (6205-11-5820) | GASKET | 1 | SN: 30001-@ |
|||
| ? | 01010-31240 | BOLT | 4 | SN: 30001-30358 |
|||
| ? | 01643-31232 | WASHER | 8 | SN: 30001-@ |
|||
| ? | 01580-01210 | NUT | 4 | SN: 30001-30358 |
|||
| ? | (6138-11-5810) | GASKET | 1 | SN: 30001-@ |
|||
| ? | 20Y-01-21560 | PIPE | 1 | SN: 30001-@ |
|||
| ? | 01010-31225 | BOLT | 4 | SN: 30001-30358 |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 30001-@ |
|||
| ? | (6138-11-5810) | GASKET | 1 | SN: 30001-@ |
|||
| ? | 20Y-54-23820 | FRAME | 1 | SN: 30001-@ |
|||
| ? | 01010-31240 | BOLT | 4 | SN: 30001-30358 |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 30001-@ |
|||
| ? | 20Y-01-21530 | BRACKET | 2 | SN: 30001-@ |
|||
| ? | 01010-31225 | BOLT | 8 | SN: 30001-30358 |
|||
| ? | 01643-31232 | WASHER | 8 | SN: 30001-@ |
|||
| ? | 20Y-01-21540 | BRACKET | 2 | SN: 30001-@ |
|||
| ? | 01010-31225 | BOLT | 4 | SN: 30001-30358 |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 30001-@ |
|||
| ? | 20Y-01-21520 | BRACKET | 2 | SN: 30001-@ |
|||
| ? | 01010-31225 | BOLT | 2 | SN: 30001-30358 |
|||
| ? | 01643-31232 | WASHER | 2 | SN: 30001-@ |
|||
| ? | 20Y-01-21510 | U-BOLT | 2 | SN: 30001-@ |
|||
| ? | 01580-01008 | NUT | 8 | SN: 30001-30358 |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 30001-@ |
|||
| ? | (6138-82-5560) | SENSOR | 1 | SN: 30001-@ |
|||
| ? | 08053-01512 | CLIP | 1 | SN: 30001-@ |
|||
| ? | 20Y-01-21620 | WIRING HARNESS | 1 | SN: 30001-30358 |
|||
| ? | (6138-12-5570) | TUBE | 1 | SN: 30001-@ |
|||
| ? | (6138-12-5580) | HOSE | 1 | SN: 30001-30358 |
|||
| ? | 07285-00100 | CLIP | 2 | SN: 30001-@ |
|||
| ? | (6138-82-5550) | SENSOR | 1 | SN: 30001-@ |
|||
| ? | 20Y-01-21550 | BRACKET | 1 | SN: 30001-30358 |
|||
| ? | 01010-30820 | BOLT | 4 | SN: 30001-30358 |
|||
| ? | 01643-50823 | WASHER | 4 | SN: 30001-@ |
|||
| ? | 20Y-01-21610 | WIRING HARNESS | 1 | SN: 30001-30358 |
|||
| ? | 08053-01512 | CLIP | 1 | SN: 30001-@ |
|||
| ? | 20Y-01-21580 | WIRING HARNESS | 1 | SN: 30001-30358 |
|||
| ? | 20Y-01-21590 | WIRING HARNESS | 1 | SN: 30001-30358 |
|||
| ? | 08034-00519 | BAND | 16 | SN: 30001-@ |
