| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (22B-60-11350) | MOTOR ASS'Y | 1 | SN: 1001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A1 ? 02A1 AND 03A1. | ||||||
| ? | TZ476B1000-00 | • FINAL DRIVE ASS'Y | 1 | SN: 1001- |
|||
| ? | (★TZ420B1001-00) | • • HUB,MOTOR | 1 | SN: 1001- |
|||
| ? | (★TZ467B1102-00) | • • SPINDLE KIT | 1 | SN: 1001- |
|||
| ? | (★TZ467B1132-00) | • • • SPINDLE ASS'Y | 1 | SN: 1001- |
|||
| ? | ☆ | • • • • SPINDLE | 1 | SN: 1001- |
|||
| ? | ☆ | • • • • FLANGE,END | 1 | SN: 1001- |
|||
| ? | TZ481B1019-00 | • • • BOLT | 3 | SN: 1001- |
|||
| ? | (★TZ671B1034-01) | • • • PIN | 3 | SN: 1001- |
|||
| ? | TZ481B1037-00 | • • • WASHER | 3 | SN: 1001- |
|||
| ? | (★TZ481B1104-01) | • • RV GEAR ASS'Y | 1 | SN: 1001- |
|||
| ? | (★TZ481B1204-00) | • • • RV GEAR KIT | 1 | SN: 1001- |
|||
| ? | ☆ | • • • • GEAR | 1 | SN: 1001- |
|||
| ? | ☆ | • • • • GEAR | 1 | SN: 1001- |
|||
| ? | ☆ | • • • SHAFT | 3 | SN: 1001- |
|||
| ? | ☆ | • • • SPACER | 6 | SN: 1001- |
|||
| ? | ☆ | • • • BEARING | 6 | SN: 1001- |
|||
| ? | ☆ | • • • BEARING | 6 | SN: 1001- |
|||
| ? | TZ482B1006-00 | • • GEAR | 1 | SN: 1001- |
|||
| ? | TZ482B1107-00 | • • SPUR GEAR KIT | 1 | SN: 1001- |
|||
| ? | ☆ | • • • SPUR GEAR | 3 | SN: 1001- |
|||
| ? | TZ481B1008-01 | • • COVER | 1 | SN: 1001- |
|||
| ? | TZ460B1024-01 | • • COUPLING | 1 | SN: 1001- |
|||
| ? | TZ225B1017-00 | • • PIN | 28 | SN: 1001- |
|||
| ? | (★TZ200A1020-00) | • • SNAP RING KIT | 3 | SN: 1001- |
|||
| ? | (★TZ481B1021-01) | • • BEARING | 2 | SN: 1001- |
|||
| ? | 04064-03515 | • • RING,BACK-UP | 3 | SN: 1001- |
|||
| ? | 07000-11007 | • • O-RING (KIT) | 2 | SN: 1001- |
|||
| ? | TZJW1516-G41-9 | • • O-RING (KIT) | 1 | SN: 1001- |
|||
| ? | TZARP568-453-7 | • • O-RING (KIT) | 1 | SN: 1001- |
|||
| ? | TZ300-328-40-B | • • FLOATING SEAL KIT | 1 | SN: 1001- |
|||
| ? | TZES100-300-B | • • • SEAL (KIT) | 2 | SN: 1001- |
|||
| ? | TZ610B2021-00 | • • PLUG | 3 | SN: 1001- |
|||
| ? | TZJB1176M12-32 | • • BOLT | 12 | SN: 1001- |
|||
| ? | 04260-01111 | • • BALL | 1 | SN: 1001- |
|||
| ? | TZJB1354-10-28 | • • PIN | 2 | SN: 1001- |
|||
| ? | 07000-12018 | • • O-RING (KIT) | 3 | SN: 1001- |
|||
| ? | SERVICE KIT | ||||||
| ? | (TZ467B9000-00) | SERVICE KIT | 1 | SN: 1001- |
