| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706-73-01121 | MOTOR ASS'Y | 1 | SN: 45001-50343 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 AND Y1640-02A0. | ||||||
| ? | (★706-73-03411) | • MOTOR SUB ASS'Y | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-43011) | • • CASE | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-72560) | • • HOUSING | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-40010) | • • BEARING | 1 | SN: 45001-@ |
|||
| ? | (★706-73-42820) | • • PIN | 1 | SN: 45001-@ |
|||
| ? | 706-77-72280 | • • PLUG | 1 | SN: 45001-50343 |
|||
| ? | 07002-12034 | • • O-RING | 1 | SN: 45001-50343 |
|||
| ? | 706-73-72420 | • • VALVE | 2 | SN: 45001-@ |
|||
| ? | 706-73-72440 | • • SPRING | 2 | SN: 45001-@ |
|||
| ? | 706-73-72430 | • • PLUG | 2 | SN: 45001-@ |
|||
| ? | 07002-12434 | • • O-RING | 2 | SN: 45001-@ |
|||
| ? | (★195-30-33190) | • • O-RING | 1 | SN: 45001-50343 |
|||
| ? | (★706-74-40320) | • • BOLT | 8 | SN: 45001-50343 |
|||
| ? | (★706-73-43860) | • • SHAFT | 1 | SN: 45001-50343 |
|||
| ? | (★706-74-41880) | • • BEARING | 1 | SN: 45001-50343 |
|||
| ? | (★706-75-40890) | • • BEARING | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-42610) | • • SPRING | 2 | SN: 45001-50343 |
|||
| ? | (★706-73-42620) | • • SEAT | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-05010) | • • SPACER KIT | 1 | SN: 45001-50343 |
|||
| ? | ☆ | • • • SPACER ? 3.0MM | 1 | SN: 45001-50343 |
|||
| ? | ☆ | • • • SPACER ? 3.4MM | 1 | SN: 45001-50343 |
|||
| ? | ☆ | • • • SPACER ? 3.8MM | 1 | SN: 45001-50343 |
|||
| ? | (★04064-04018) | • • RING | 1 | SN: 45001-50343 |
|||
| ? | 708-8D-12210 | • • SEAL | 1 | SN: 45001-50343 |
|||
| ? | 706-73-42711 | • • COVER | 1 | SN: 45001-50343 |
|||
| ? | 07000-02080 | • • O-RING | 1 | SN: 45001-50343 |
|||
| ? | 04065-08530 | • • RING | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-41091) | • • BLOCK | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-42740) | • • PLATE | 1 | SN: 45001-50343 |
|||
| ? | (★04020-00616) | • • PIN | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-42180) | • • SHAFT | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-41130) | • • RING | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-41220) | • • BALL | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-41110) | • • SPRING | 1 | SN: 45001-@ |
|||
| ? | (★706-73-05020) | • • RETAINER KIT | 1 | SN: 45001-@ |
|||
| ? | ☆ | • • • RETAINER | 1 | SN: 45001-@ |
|||
| ? | ☆ | • • • SCREW | 7 | SN: 45001-@ |
|||
| ? | (★706-73-41164) | • • PISTON ASS'Y | 7 | SN: 45001-50343 |
|||
| ? | (★706-73-92130) | • • PLATE | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-92140) | • • PLATE | 3 | SN: 45001-50343 |
|||
| ? | (★706-75-90050) | • • DISK | 3 | SN: 45001-50343 |
|||
| ? | (★706-73-92180) | • • PISTON,BRAKE | 1 | SN: 45001-50343 |
|||
| ? | (★07000-12130) | • • O-RING | 1 | SN: 45001-50343 |
|||
| ? | (★07000-12145) | • • O-RING | 1 | SN: 45001-50343 |
|||
| ? | (★706-73-92160) | • • SPRING | 1 | SN: 45001-50343 |
