| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 203-70-44490 | LINK,L.H. | 1 | SN: .-24392 |
|||
| ? | 203-70-44510 | LINK,R.H. | 1 | SN: .-24392 |
|||
| ? | 203-70-44350 | PIN | 1 | SN: 18001-24392 |
|||
| ? | 07020-00000 | FITTING,GREASE | 1 | SN: 18001-@ |
|||
| ? | 203-70-24150 | SPACER ? 1.0MM | 1 | SN: 18001-@ |
|||
| ? | 203-70-24160 | SPACER ? 2.0MM | 1 | SN: 18001-@ |
|||
| ? | 01011-51620 | BOLT | 1 | SN: 18001-@ |
|||
| ? | 01580-11613 | NUT | 2 | SN: 18001-@ |
|||
| ? | 203-70-44360 | PIN | 1 | SN: 18001-24392 |
|||
| ? | 07020-00000 | FITTING,GREASE | 1 | SN: 18001-@ |
|||
| ? | 202-70-48460 | SPACER ? 1.0MM | 2 | SN: 18001-@ |
|||
| ? | 01011-51620 | BOLT | 1 | SN: 18001-@ |
|||
| ? | 01580-11613 | NUT | 2 | SN: 18001-@ |
|||
| ? | 203-70-00142 | LINK ASS'Y | 2 | SN: 21100-24392 |
|||
| ? | □203-70-00141 | LINK ASS'Y | 2 | SN: 18321-21099 |
|||
| ? | ☆ | • LINK | 1 | SN: 18321-24392 |
|||
| ? | 203-70-44331 | • BUSHING | 1 | SN: 21100-@ |
|||
| ? | □203-70-44330 | • BUSHING | 1 | SN: 18321-21099 |
|||
| ? | 203-70-33150 | • BUSHING | 1 | SN: 18321-24392 |
|||
| ? | 203-70-44230 | SEAL,DUST | 4 | SN: 18001-24392 |
|||
| ? | 203-70-33210 | SEAL,DUST | 4 | SN: 18001-24392 |
|||
| ? | 203-70-44371 | PIN | 1 | SN: 21100-24392 |
|||
| ? | □203-70-44370 | PIN | 1 | SN: 18001-21099 |
|||
| ? | 07020-00000 | FITTING,GREASE | 1 | SN: 18001-24392 |
|||
| ? | 203-70-24150 | SPACER ? 1.0MM | 1 | SN: 18001-@ |
|||
| ? | 203-70-24160 | SPACER ? 2.0MM | 1 | SN: 18001-24392 |
|||
| ? | 01011-51640 | BOLT | 1 | SN: 18001-@ |
|||
| ? | 01580-11613 | NUT | 2 | SN: 18001-@ |
|||
| ? | 203-70-44380 | PIN | 1 | SN: 18001-@ |
|||
| ? | 203-70-44452 | SPACER | 1 | SN: .-24392 |
|||
| ? | □203-70-44451 | SPACER | 1 | SN: 18001-. |
|||
| ? | 203-70-44441 | PLATE | 1 | SN: .-24392 |
|||
| ? | □203-70-44440 | PLATE | 1 | SN: 18001-. |
|||
| ? | 203-70-44460 | SHIM ? 0.5MM | 4 | SN: 18001-24392 |
|||
| ? | 203-70-44550 | SHIM ? 1.0MM | 8 | SN: 18001-24392 |
|||
| ? | 203-70-44470 | O-RING | 2 | SN: 18001-@ |
|||
| ? | 01011-51670 | BOLT | 1 | SN: 18001-@ |
|||
| ? | 01580-11613 | NUT | 2 | SN: 18001-@ |
|||
| ? | 01010-51470 | BOLT | 4 | SN: 18001-24392 |
|||
| ? | 01643-31445 | WASHER | 4 | SN: 18001-24392 |
