| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-57-12305) | CONTROL VALVE | 1 | SN: 46925- |
|||
| ? | (723-57-12304) | CONTROL VALVE | 1 | SN: 46808-46924 |
|||
| ? | (723-57-12303) | CONTROL VALVE | 1 | SN: 46721-46807 |
|||
| ? | (723-57-12302) | CONTROL VALVE | 1 | SN: 46604-46720 |
|||
| ? | (723-57-12301) | CONTROL VALVE | 1 | SN: 46458-46603 |
|||
| ? | (723-57-12300) | CONTROL VALVE | 1 | SN: 46059-46457 |
|||
| ? | (723-57-11303) | CONTROL VALVE | 1 | SN: 45786-46058 |
|||
| ? | (723-57-11302) | CONTROL VALVE | 1 | SN: 45685-45785 |
|||
| ? | (723-57-11301) | CONTROL VALVE | 1 | SN: 45179-45684 |
|||
| ? | (723-57-11300) | CONTROL VALVE | 1 | SN: 45000-45178 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1663-21A0 TO Y1663-33A0. | ||||||
| ? | ☆ | • BLOCK GROUP | 1 | SN: 45000- |
|||
| ? | ☆ | • • BLOCK | 1 | SN: 45000- |
|||
| ? | 144-14-54610 | • • O-RING | 1 | SN: 45000- |
|||
| ? | 723-56-31730 | • • O-RING | 1 | SN: 45000- |
|||
| ? | 702-75-11520 | • • O-RING | 1 | SN: 45000- |
|||
| ? | 07000-11008 | • • O-RING | 1 | SN: 45000- |
|||
| ? | ☆ | • • SLEEVE | 2 | SN: 45000- |
|||
| ? | ☆ | • • PISTON | 1 | SN: 45000- |
|||
| ? | 723-36-15340 | • • SPRING | 1 | SN: 45000- |
|||
| ? | ☆ | • • PISTON | 1 | SN: 45000- |
|||
| ? | 723-36-15240 | • • SPRING | 1 | SN: 45000- |
|||
| ? | 723-36-15250 | • • CASE | 2 | SN: 45000- |
|||
| ? | 07000-13042 | • • O-RING | 2 | SN: 45000- |
|||
| ? | 01252-60820 | • • BOLT | 4 | SN: 45000- |
|||
| ? | ☆ | • COVER GROUP | 1 | SN: 45000- |
|||
| ? | ☆ | • • COVER | 1 | SN: 45000- |
|||
| ? | 723-50-11311 | • • PLUG | 1 | SN: 45000- |
|||
| ? | 07000-11004 | • • O-RING | 1 | SN: 45000- |
|||
| ? | 07001-01004 | • • RING | 1 | SN: 45000- |
|||
| ? | 07002-11423 | • • O-RING | 1 | SN: 45000- |
|||
| ? | 723-26-15190 | • • PLUG | 1 | SN: 45000- |
|||
| ? | 07000-11007 | • • O-RING | 1 | SN: 45000- |
|||
| ? | 07001-01007 | • • RING,BACK-UP | 1 | SN: 45000- |
|||
| ? | 07000-11009 | • • O-RING | 1 | SN: 45000- |
|||
| ? | 07001-01009 | • • RING,BACK-UP | 1 | SN: 45000- |
|||
| ? | 708-8E-16160 | • • PLUG | 2 | SN: 45000- |
|||
| ? | 07002-11023 | • • O-RING | 2 | SN: 45000- |
|||
| ? | 07040-11409 | • • PLUG | 1 | SN: 45000- |
|||
| ? | 706-73-71450 | • • PLUG | 1 | SN: 45000- |
|||
| ? | 07002-11423 | • • O-RING | 2 | SN: 45000- |
|||
| ? | 723-50-11170 | • STUD | 4 | SN: 45000- |
|||
| ? | 01643-31232 | • WASHER | 4 | SN: 45000- |
|||
| ? | 01580-11210 | • NUT | 4 | SN: 45000- |
|||
| ? | 01252-60850 | • BOLT | 11 | SN: 45000- |
|||
| ? | 708-25-19160 | • BOLT | 4 | SN: 45000- |
|||
| ? | 01252-60865 | • BOLT | 2 | SN: 45000- |
