| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-37-10204) | CONTROL VALVE | 1 | SN: 41230-41400 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1662-41A0A T0 Y1662-50A0A . | ||||||
| ? | 709-70-74302 | • VALVE ASS'Y,SUCTION AND SAFETY | 4 | SN: 41230-41400 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • POPPET | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • PISTON | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • PLUG | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • POPPET | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SCREW | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SEAL | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SEAL | 1 | SN: 41230-41400 |
|||
| ? | 709-25-11390 | • • O-RING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • O-RING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • O-RING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • NUT | 1 | SN: 41230-41400 |
|||
| ? | 709-70-74402 | • VALVE ASS'Y,SUCTION AND SAFETY | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • POPPET | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • PISTON | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • PLUG | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • POPPET | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SCREW | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SEAL | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SEAL | 1 | SN: 41230-41400 |
|||
| ? | 709-25-11390 | • • O-RING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • O-RING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • O-RING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • NUT | 1 | SN: 41230-41400 |
|||
| ? | 723-40-85100 | • VALVE ASS'Y,SUCTION | 5 | SN: 41230-41400 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • VALVE | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 41230-41400 |
|||
| ? | ☆ | • • SEAL | 1 | SN: 41230-41400 |
|||
| ? | 709-25-11390 | • • O-RING | 1 | SN: 41230-41400 |
