| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706-73-01181 | MOTOR ASS'Y | 1 | SN: 45613- |
|||
| ? | 706-73-01180 | MOTOR ASS'Y | 1 | SN: 45000-45612 |
|||
| ? | 706-73-01161 | MOTOR ASS'Y | 1 | SN: 42157-44999 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1640-01A0A AND Y1640-02A0 A. | ||||||
| ? | 706-73-03511 | • MOTOR SUB ASS'Y | 1 | SN: 42157- |
|||
| ? | (★706-73-43110) | • • CASE,MOTOR | 1 | SN: 42157- |
|||
| ? | (★706-73-00020) | • • HOUSING SUB ASS'Y | 1 | SN: 42157- |
|||
| ? | ☆ | • • • HOUSING | 1 | SN: 42157- |
|||
| ? | ☆ | • • • PLUG | 2 | SN: 42157- |
|||
| ? | ☆ | • • • PLUG | 1 | SN: 42157- |
|||
| ? | (★706-73-40010) | • • BEARING | 1 | SN: 40001- |
|||
| ? | (★706-73-42820) | • • PIN | 1 | SN: 40001- |
|||
| ? | 706-73-72680 | • • PLUG | 1 | SN: 42157- |
|||
| ? | 07002-11223 | • • O-RING | 1 | SN: 42157- |
|||
| ? | 709-25-11650 | • • VALVE,CHECK | 2 | SN: 42157- |
|||
| ? | 709-25-11361 | • • SPRING | 2 | SN: 42157- |
|||
| ? | 709-25-11640 | • • PLUG | 2 | SN: 42157- |
|||
| ? | 07000-12020 | • • O-RING | 2 | SN: 42157- |
|||
| ? | 706-73-72420 | • • VALVE | 2 | SN: 40001- |
|||
| ? | 706-73-72440 | • • SPRING | 2 | SN: 40001- |
|||
| ? | 706-73-72430 | • • PLUG | 2 | SN: 40001- |
|||
| ? | 07002-12434 | • • O-RING | 2 | SN: 40001- |
|||
| ? | (★07000-02145) | • • O-RING | 1 | SN: 42157- |
|||
| ? | (★01252-61240) | • • BOLT | 6 | SN: 42157- |
|||
| ? | (★706-73-43960) | • • SHAFT,DRIVE | 1 | SN: 42157- |
|||
| ? | (★706-73-43880) | • • BEARING | 1 | SN: 42157- |
|||
| ? | (★706-73-43810) | • • SPACER | 1 | SN: 42157- |
|||
| ? | (★706-73-43610) | • • SPRING | 2 | SN: 42157- |
|||
| ? | (★706-73-43620) | • • SEAT | 1 | SN: 42157- |
|||
| ? | (★706-73-43890) | • • BEARING | 1 | SN: 42157- |
|||
| ? | (★706-73-05030) | • • SPACER KIT | 1 | SN: 42157- |
|||
| ? | ☆ | • • • SPACER ? 2.1MM | 1 | SN: 42157- |
|||
| ? | ☆ | • • • SPACER ? 2.4MM | 1 | SN: 42157- |
|||
| ? | ☆ | • • • SPACER ? 2.7MM | 1 | SN: 42157- |
|||
| ? | (★04064-03515) | • • RING,SNAP | 1 | SN: 42157- |
|||
| ? | 708-7T-12230 | • • SEAL,OIL | 1 | SN: 42157- |
|||
| ? | 04065-04518 | • • RING,SNAP | 1 | SN: 42157- |
|||
| ? | (★706-73-43190) | • • BLOCK,CYLINDER | 1 | SN: 42157- |
|||
| ? | (★706-73-43742) | • • PLATE,VALVE | 1 | SN: 42157- |
|||
| ? | (★720-68-19610) | • • PIN | 1 | SN: 42157- |
|||
| ? | (★706-73-43120) | • • SHAFT,CENTER | 1 | SN: 42157- |
|||
| ? | (★706-73-43130) | • • RING,CENTER | 1 | SN: 42157- |
|||
| ? | (★706-73-41110) | • • SPRING | 1 | SN: 40001- |
|||
| ? | (★706-73-05020) | • • RETAINER KIT | 1 | SN: 40001- |
|||
| ? | ☆ | • • • RETAINER | 1 | SN: 40001- |
|||
| ? | ☆ | • • • SCREW | 7 | SN: 40001- |
|||
| ? | (★706-73-43160) | • • PISTON SUB ASS'Y | 7 | SN: 42157- |
|||
| ? | (★706-73-92340) | • • PLATE | 4 | SN: 42157- |
|||
| ? | (★706-73-92350) | • • DISK | 3 | SN: 42157- |
|||
| ? | (★706-73-92380) | • • PISTON,BRAKE | 1 | SN: 42157- |
|||
| ? | (★706-73-92390) | • • RING,BRAKE | 1 | SN: 42157- |
|||
| ? | (★07000-12115) | • • O-RING | 1 | SN: 42157- |
|||
| ? | (★07000-12130) | • • O-RING | 2 | SN: 42157- |
|||
| ? | (★708-7T-15150) | • • SPRING | 4 | SN: 42157- |
