| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (☉202-63-X2322) | CYLINDER GROUP | 1 | SN: 40624-41229 |
|||
| ? | (☉202-63-X2321) | CYLINDER GROUP | 1 | SN: 40001-40623 |
|||
| ? | ==================== | ||||||
| ? | 202-63-02322 | CYLINDER ASS'Y,ARM | 1 | SN: 40624-@ |
|||
| ? | □202-63-02321 | CYLINDER ASS'Y,ARM | 1 | SN: 40001-40623 |
|||
| ? | 202-63-64342 | • CYLINDER,ARM | 1 | SN: 40624-@ |
|||
| ? | □202-63-64341 | • CYLINDER,ARM | 1 | SN: 40001-40623 |
|||
| ? | 707-76-70240 | • BUSHING | 1 | SN: 40001-@ |
|||
| ? | 07145-00070 | • SEAL,DUST (KIT) | 2 | SN: 40001-@ |
|||
| ? | 707-71-32510 | • COLLAR | 1 | SN: 40001-41229 |
|||
| ? | 07000-15110 | • O-RING (KIT) | 1 | SN: 40001-@ |
|||
| ? | 07001-05110 | • RING,BACK-UP (KIT) | 2 | SN: 40001-@ |
|||
| ? | 707-27-11670 | • HEAD,CYLINDER | 1 | SN: 40001-@ |
|||
| ? | 707-52-90500 | • BUSHING | 1 | SN: 40001-@ |
|||
| ? | 707-51-75030 | • PACKING,ROD (KIT) | 1 | SN: 40001-@ |
|||
| ? | 707-51-75630 | • RING,BUFFER (KIT) | 1 | SN: 40001-@ |
|||
| ? | 07000-15110 | • O-RING (KIT) | 1 | SN: 40001-@ |
|||
| ? | 07001-05110 | • RING,BACK-UP (KIT) | 1 | SN: 40001-@ |
|||
| ? | 144-63-94170 | • SEAL,DUST (KIT) | 1 | SN: 40001-@ |
|||
| ? | 07179-13089 | • RING,SNAP | 1 | SN: 40001-@ |
|||
| ? | 01010-81670 | • BOLT | 12 | SN: 40001-@ |
|||
| ? | 01643-51645 | • WASHER | 12 | SN: 40001-@ |
|||
| ? | 202-63-64321 | • ROD | 1 | SN: 40624-@ |
|||
| ? | □202-63-64320 | ROD | 1 | SN: 40001-40623 |
|||
| ? | 707-71-60200 | • PLUNGER | 1 | SN: 40001-@ |
|||
| ? | 04260-00635 | • BALL | 11 | SN: 40001-@ |
|||
| ? | 707-71-91270 | • CAP | 1 | SN: 40001-@ |
|||
| ? | 707-76-70240 | • BUSHING | 1 | SN: 40001-@ |
|||
| ? | 07145-00070 | • SEAL,DUST (KIT) | 2 | SN: 40001-@ |
|||
| ? | 707-71-60830 | • PLUNGER | 1 | SN: 40001-@ |
|||
| ? | 707-40-11470 | • RETAINER | 1 | SN: 40001-@ |
|||
| ? | 707-36-11510 | • PISTON | 1 | SN: 40001-@ |
|||
| ? | 707-44-11280 | • RING,PISTON (KIT) | 1 | SN: 40001-@ |
|||
| ? | 707-39-11510 | • RING,WEAR (KIT) | 2 | SN: 40001-@ |
|||
| ? | 707-44-11920 | • RING | 2 | SN: 40001-@ |
|||
| ? | 07165-15860 | • NUT,NYLON | 1 | SN: 40001-@ |
|||
| ? | 202-63-64371 | TUBE | 1 | SN: 40001-@ |
|||
| ? | 707-87-11450 | ELBOW | 1 | SN: 40001-41229 |
|||
| ? | 07000-13025 | O-RING (KIT) | 2 | SN: 40001-@ |
|||
| ? | 01010-50850 | BOLT | 8 | SN: 40001-41229 |
|||
| ? | 01643-50823 | WASHER | 8 | SN: 40001-@ |
|||
| ? | 707-88-95350 | BAND | 1 | SN: 40001-40419 |
|||
| ? | 707-88-95502 | BRACKET | 1 | SN: 40001-40419 |
|||
| ? | 707-88-95360 | BAND | 1 | SN: 40001-@ |
|||
| ? | 707-88-95510 | BRACKET | 1 | SN: 40001-@ |
|||
| ? | 01010-51035 | BOLT | 2 | SN: 40420-@ |
|||
| ? | □01010-51035 | BOLT | 4 | SN: 40001-40419 |
|||
| ? | 01643-51032 | WASHER | 2 | SN: 40420-@ |
|||
| ? | □01643-51032 | WASHER | 4 | SN: 40001-40419 |
|||
| ? | 07283-22236 | CLIP | 1 | SN: 40420-@ |
|||
| ? | □07283-22236 | CLIP | 2 | SN: 40001-40419 |
|||
| ? | 01599-01011 | NUT | 2 | SN: 40420-@ |
|||
| ? | □01599-01011 | NUT | 4 | SN: 40001-40419 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 40420-@ |
|||
| ? | □01643-31032 | WASHER | 4 | SN: 40001-40419 |
|||
| ? | ==================== | ||||||
| ? | 707-99-44200 | SERVICE KIT | 1 | SN: 40001-@ |
