| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (702-16-01651) | VALVE ASS'Y | 1 | SN: 46059-@ |
|||
| ? | (□702-16-01650) | PILOT VALVE | 1 | SN: 40001-46058 |
|||
| ? | 07230-20210 | UNION | 3 | SN: 40001-@ |
|||
| ? | 07002-01423 | O-RING | 3 | SN: 40001-@ |
|||
| ? | 07235-10210 | ELBOW | 1 | SN: 40001-@ |
|||
| ? | 07002-01423 | O-RING | 1 | SN: 40001-@ |
|||
| ? | 203-62-62321 | HOSE ? 2100MM | 2 | SN: 45000-46058 |
|||
| ? | 203-62-62331 | HOSE ? 1370MM | 1 | SN: 40001-46058 |
|||
| ? | 203-62-62341 | HOSE ? 1570MM | 1 | SN: 40001-46058 |
|||
| ? | 203-62-62521 | HOSE ? 2200MM | 1 | SN: 45000-46058 |
|||
| ? | 203-62-62830 | HOSE ? 2000MM | 1 | SN: 40001-46058 |
|||
| ? | 20Y-62-22790 | BAND ? RED | 2 | SN: 45000-@ |
|||
| ? | 20Y-62-22820 | BAND ? BLUE | 2 | SN: 45000-@ |
|||
| ? | 20Y-62-22830 | BAND ? WHITE | 2 | SN: 45000-@ |
|||
| ? | 20Y-62-22840 | BAND ? BLACK | 2 | SN: 45000-@ |
|||
| ? | 20Y-62-22850 | BAND ? GREEN | 2 | SN: 45000-@ |
|||
| ? | 20Y-62-22860 | BAND ? BROWN | 2 | SN: 45000-@ |
|||
| ? | 07000-02018 | O-RING | 2 | SN: 40001-@ |
|||
| ? | 07000-02015 | O-RING | 2 | SN: 40001-@ |
|||
| ? | 20Y-62-18910 | BOLT | 1 | SN: 40001-@ |
|||
| ? | 20Y-62-18890 | BOLT | 1 | SN: 40001-@ |
|||
| ? | 01010-80820 | BOLT | 4 | SN: 45000-46058 |
|||
| ? | 01643-30823 | WASHER | 4 | SN: 40001-46058 |
