| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-1L-00471) | PUMP ASS'Y | 1 | SN: 1191- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0A T0 Y1600-10A0A . | ||||||
| ? | 01010-81085 | • BOLT | 3 | SN: 1191- |
|||
| ? | 01643-51032 | • WASHER | 3 | SN: 1191- |
|||
| ? | 07000-02070 | • O-RING | 1 | SN: 1191- |
|||
| ? | 07000-02018 | • O-RING | 1 | SN: 1191- |
|||
| ? | 708-2L-29140 | • COUPLING | 1 | SN: 1191- |
|||
| ? | 708-2L-29211 | • COLLAR | 1 | SN: 1191- |
|||
| ? | 702-21-07010 | • SOLENOID VALVE ASS'Y | 1 | SN: 1191- |
|||
| ? | (★708-2L-04280) | • BLOCK ASS'Y | 1 | SN: 1191- |
|||
| ? | ☆ | • • BLOCK | 1 | SN: 1191- |
|||
| ? | ☆ | • • PLUG | 4 | SN: 1191- |
|||
| ? | 708-2L-23970 | • • O-RING | 1 | SN: 1191- |
|||
| ? | 07040-11007 | • PLUG | 1 | SN: 1191- |
|||
| ? | 708-2L-23920 | • O-RING | 1 | SN: 1191- |
|||
| ? | 01252-30865 | • BOLT | 2 | SN: 1191- |
|||
| ? | 203-60-62220 | • BOLT | 2 | SN: 1191- |
|||
| ? | 07235-10210 | • ELBOW | 1 | SN: 1191- |
|||
| ? | 708-2L-23950 | • O-RING | 1 | SN: 1191- |
|||
| ? | 07230-20210 | • UNION | 1 | SN: 1191- |
|||
| ? | 708-2L-23950 | • O-RING | 1 | SN: 1191- |
|||
| ? | 01582-11008 | • NUT | 1 | SN: 1191- |
|||
| ? | 708-1L-29310 | • HOSE | 1 | SN: 1191- |
|||
| ? | 708-2L-29410 | • HOSE | 1 | SN: 1191- |
|||
| ? | 708-2L-23960 | • O-RING | 2 | SN: 1191- |
|||
| ? | 07000-B2011 | • O-RING | 2 | SN: 1191- |
|||
| ? | 708-1L-29330 | • ELBOW | 1 | SN: 1191- |
|||
| ? | 708-2L-23950 | • O-RING | 1 | SN: 1191- |
|||
| ? | 708-1L-29340 | • ORIFICE | 1 | SN: 1191- |
