| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-1L-00471) | PUMP ASS'Y | 1 | SN: 1191- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0A T0 Y1600-10A0A . | ||||||
| ? | (708-1L-01451) | • PUMP SUB ASS'Y | 1 | SN: 1191- |
|||
| ? | (★708-2L-04141) | • • BLOCK ASS'Y,FRONT | 1 | SN: 1191- |
|||
| ? | ☆ | • • • BLOCK,CYLINDER | 1 | SN: 1191- |
|||
| ? | ☆ | • • • PLATE,VALVE | 1 | SN: 1191- |
|||
| ? | (★720-68-19610) | • • PIN | 1 | SN: 1191- |
|||
| ? | (★04065-04818) | • • RING,SNAP | 1 | SN: 1191- |
|||
| ? | (★708-2L-23131) | • • SEAT | 1 | SN: 1191- |
|||
| ? | (★708-2L-33160) | • • SPRING | 1 | SN: 1191- |
|||
| ? | (★708-7L-13140) | • • SEAT | 1 | SN: 1191- |
|||
| ? | (★708-2L-23351) | • • GUIDE,RETAINER | 1 | SN: 1191- |
|||
| ? | (★708-2L-23360) | • • PIN | 3 | SN: 1191- |
|||
| ? | (★708-2L-33340) | • • RETAINER,SHOE | 1 | SN: 1191- |
|||
| ? | (★708-2L-33310) | • • PISTON SUB ASS'Y | 9 | SN: 1191- |
|||
| ? | (★708-2L-04361) | • • CRADLE ASS'Y,FRONT | 1 | SN: 1191- |
|||
| ? | ☆ | • • • CRADLE | 1 | SN: 1191- |
|||
| ? | ☆ | • • • CAM,ROCKER | 1 | SN: 1191- |
|||
| ? | (★04020-01228) | • • PIN | 1 | SN: 1191- |
|||
| ? | (★07000-B1009) | • • O-RING | 1 | SN: 1191- |
|||
| ? | (★01252-61230) | • • BOLT | 4 | SN: 1191- |
