| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (700-85-48001) | VALVE ASS'Y,R.H. | 1 | SN: 32402- |
|||
| ? | (700-85-38003) | VALVE ASS'Y,R.H. | 1 | SN: 28001-32401 |
|||
| ? | (☒700-85-38002) | VALVE ASS'Y,R.H. | 1 | SN: (28001-29805) |
|||
| ? | 709-70-55300 | • VALVE ASS'Y,RELIEF | 1 | SN: 28001- |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 28001- |
|||
| ? | 709-70-51420 | • • POPPET | 1 | SN: 28001- |
|||
| ? | 709-70-51230 | • • SPRING | 1 | SN: 28001- |
|||
| ? | 700-20-51340 | • • SCREW | 1 | SN: 28001- |
|||
| ? | 07000-02011 | • • O-RING | 1 | SN: 28001- |
|||
| ? | 01582-11411 | • • NUT | 1 | SN: 28001- |
|||
| ? | 700-22-11410 | • • O-RING | 1 | SN: 28001- |
|||
| ? | 07002-02434 | • • O-RING | 1 | SN: 28001- |
|||
| ? | 700-20-51550 | • • RING | 1 | SN: 28001- |
|||
| ? | ☆ | • • VALVE | 1 | SN: 28001- |
|||
| ? | 709-70-51210 | • • SPRING | 1 | SN: 28001- |
|||
| ? | 700-20-51540 | • • RETAINER | 1 | SN: 28001- |
|||
| ? | 709-70-74501 | • VALVE ASS'Y,SUCTION AND SAFETY | 1 | SN: 32402- |
|||
| ? | 709-70-71500 | • VALVE ASS'Y,SUCTION AND SAFETY | 1 | SN: 28001-32401 |
|||
| ? | 709-70-71112 | • • SLEEVE | 1 | SN: 32402- |
|||
| ? | 709-70-71511 | • • SLEEVE | 1 | SN: 28001-32401 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 28001- |
|||
| ? | ☆ | • • POPPET | 1 | SN: 28001- |
|||
| ? | ☆ | • • SEAL | 1 | SN: 28001- |
|||
| ? | ☆ | • • PISTON | 1 | SN: 28001- |
|||
| ? | 709-70-71210 | • • SPRING | 1 | SN: 28001- |
|||
| ? | ☆ | • • PLUG | 1 | SN: 28001- |
|||
| ? | ☆ | • • SEAL | 1 | SN: 28001- |
|||
| ? | 709-70-71220 | • • SPRING | 1 | SN: 28001- |
|||
| ? | 07002-02434 | • • O-RING | 1 | SN: 28001- |
|||
| ? | ☆ | • • POPPET | 1 | SN: 28001- |
|||
| ? | ☆ | • • SPRING | 1 | SN: 28001- |
|||
| ? | ☆ | • • SCREW | 1 | SN: 28001- |
|||
| ? | ☆ | • • O-RING | 1 | SN: 28001- |
|||
| ? | ☆ | • • NUT | 1 | SN: 28001- |
|||
| ? | 700-22-11410 | • • O-RING | 1 | SN: 28001-32401 |
|||
| ? | 700-80-64220 | • • RING,BACK-UP | 1 | SN: 28001-32401 |
|||
| ? | 709-25-11390 | • • O-RING | 1 | SN: 32402- |
|||
| ? | 07002-03034 | • • O-RING | 1 | SN: 28001-32401 |
|||
| ? | 709-20-81201 | • VALVE ASS'Y,SUCTION | 1 | SN: 32402- |
|||
| ? | 700-81-82001 | • VALVE ASS'Y,SUCTION | 1 | SN: 28001-32401 |
|||
| ? | 709-20-61110 | • • SLEEVE | 1 | SN: 32402- |
|||
| ? | 700-80-62310 | • • SLEEVE | 1 | SN: 28001-32401 |
|||
| ? | ☆ | • • VALVE | 1 | SN: 32402- |
|||
| ? | ☆ | • • VALVE | 1 | SN: 28001-32401 |
|||
| ? | 709-20-61160 | • • SPRING | 1 | SN: 32402- |
|||
| ? | 700-80-62250 | • • SPRING | 1 | SN: 28001-32401 |
|||
| ? | ☆ | • • SEAL | 1 | SN: 32402- |
|||
| ? | ☆ | • • SEAL | 1 | SN: 28001-32401 |
|||
| ? | 709-25-11390 | • • O-RING | 1 | SN: 32402- |
|||
| ? | 07002-03034 | • • O-RING | 1 | SN: 28001-32401 |
|||
| ? | 709-70-74402 | • VALVE ASS'Y,SUCTION AND SAFETY | 1 | SN: 32402- |
|||
| ? | 709-70-71404 | • VALVE ASS'Y,SUCTION AND SAFETY | 1 | SN: 28001-32401 |
|||
| ? | 709-70-71112 | • • SLEEVE | 1 | SN: 32402- |
|||
| ? | 709-70-71511 | • • SLEEVE | 1 | SN: 28001-32401 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 28001- |
|||
| ? | ☆ | • • POPPET | 1 | SN: 28001- |
|||
| ? | ☆ | • • SEAL | 1 | SN: 28001- |
|||
| ? | ☆ | • • PISTON | 1 | SN: 28001- |
|||
| ? | 709-70-71210 | • • SPRING | 1 | SN: 28001- |
|||
| ? | ☆ | • • PLUG | 1 | SN: 28001- |
|||
| ? | ☆ | • • SEAL | 1 | SN: 28001- |
|||
| ? | 709-70-71220 | • • SPRING | 1 | SN: 28001- |
|||
| ? | 07002-02434 | • • O-RING | 1 | SN: 28001- |
|||
| ? | ☆ | • • POPPET | 1 | SN: 28001- |
|||
| ? | ☆ | • • SPRING | 1 | SN: 28001- |
|||
| ? | ☆ | • • SCREW | 1 | SN: 28001- |
|||
| ? | ☆ | • • O-RING | 1 | SN: 28001- |
|||
| ? | ☆ | • • NUT | 1 | SN: 28001- |
|||
| ? | 700-22-11410 | • • O-RING | 1 | SN: 28001-32401 |
|||
| ? | 700-80-64220 | • • RING,BACK-UP | 1 | SN: 28001-32401 |
|||
| ? | 709-25-11390 | • • O-RING | 1 | SN: 32402- |
|||
| ? | 07002-03034 | • • O-RING | 1 | SN: 28001-32401 |
