| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-27-50600) | CONTROL VALVE | 1 | SN: 6501- |
|||
| ? | (723-27-50300) | CONTROL VALVE | 1 | SN: 4001-6500 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-61A0 TO Y1662-83A0. | ||||||
| ? | ☆ | • BODY GROUP | 1 | SN: 6501- |
|||
| ? | ☆ | • BODY GROUP | 1 | SN: 4001-6500 |
|||
| ? | 723-11-00911 | • • CASE SUB ASS'Y | 3 | SN: 4001- |
|||
| ? | ☆ | • • • CASE,SPRING | 1 | SN: 4001- |
|||
| ? | 722-12-19120 | • • • O-RING | 1 | SN: 4001- |
|||
| ? | ☆ | • • • PLUG | 1 | SN: 4001- |
|||
| ? | 07002-10823 | • • • O-RING | 1 | SN: 4001- |
|||
| ? | ☆ | • • • SEAT | 1 | SN: 4001- |
|||
| ? | ☆ | • • • BALL | 1 | SN: 4001- |
|||
| ? | 702-21-54260 | • • • O-RING | 1 | SN: 4001- |
|||
| ? | 723-11-01220 | • • CASE SUB ASS'Y | 1 | SN: 4001- |
|||
| ? | ☆ | • • • CASE,SPRING | 1 | SN: 4001- |
|||
| ? | 722-12-19120 | • • • O-RING | 1 | SN: 4001- |
|||
| ? | ☆ | • • • PLUG | 1 | SN: 4001- |
|||
| ? | 07002-10823 | • • • O-RING | 1 | SN: 4001- |
|||
| ? | ☆ | • • • SEAT | 1 | SN: 4001- |
|||
| ? | ☆ | • • • BALL | 1 | SN: 4001- |
|||
| ? | 702-21-54260 | • • • O-RING | 1 | SN: 4001- |
|||
| ? | 723-11-27880 | • • CASE,SPRING | 2 | SN: 4001- |
|||
| ? | 722-12-19120 | • • O-RING | 2 | SN: 4001- |
|||
| ? | 723-11-17410 | • • CASE,SPRING | 1 | SN: 4001- |
|||
| ? | 722-12-19120 | • • O-RING | 1 | SN: 4001- |
|||
| ? | 01252-60640 | • • BOLT | 12 | SN: 4001- |
|||
| ? | 01252-60635 | • • BOLT | 4 | SN: 4001- |
|||
| ? | 01252-60620 | • • BOLT | 2 | SN: 4001- |
