| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-27-50500) | CONTROL VALVE | 1 | SN: 6501- |
|||
| ? | (723-27-50101) | CONTROL VALVE | 1 | SN: 4001-6500 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-23A0. | ||||||
| ? | ☆ | • BODY GROUP | 1 | SN: 6501- |
|||
| ? | ☆ | • BODY GROUP | 1 | SN: 4001-6500 |
|||
| ? | ☆ | • • SPOOL | 2 | SN: 6501- |
|||
| ? | ☆ | • • SPOOL | 2 | SN: 4001-6500 |
|||
| ? | ☆ | • • SPOOL | 1 | SN: 4001- |
|||
| ? | ☆ | • • SPOOL | 1 | SN: 4001- |
|||
| ? | 723-11-27260 | • • PLUG | 1 | SN: 4001- |
|||
| ? | 723-11-17470 | • • PLUG | 1 | SN: 4001- |
|||
| ? | 07002-10823 | • • O-RING | 2 | SN: 4001- |
|||
| ? | 723-11-17490 | • • POPPET | 2 | SN: 4001- |
|||
| ? | 723-11-17510 | • • SPRING | 2 | SN: 4001- |
|||
| ? | 723-11-37130 | • • RETAINER | 4 | SN: 6501- |
|||
| ? | 723-11-17330 | • • RETAINER | 1 | SN: 6501- |
|||
| ? | 723-11-17330 | • • RETAINER | 3 | SN: 4001-6500 |
|||
| ? | 723-11-17353 | • • RETAINER | 1 | SN: 6501- |
|||
| ? | 723-11-17353 | • • RETAINER | 3 | SN: 4001-6500 |
|||
| ? | 723-11-17341 | • • SPRING | 4 | SN: 6501- |
|||
| ? | 723-11-17341 | • • SPRING | 2 | SN: 4001-6500 |
|||
| ? | 723-11-16991 | • • SPRING | 1 | SN: 4001- |
|||
| ? | 723-11-17361 | • • BOLT | 1 | SN: 6501- |
|||
| ? | 723-11-17361 | • • BOLT | 3 | SN: 4001-6500 |
|||
| ? | 723-11-27771 | • • PLUG | 1 | SN: 4001- |
|||
| ? | 723-11-29690 | • • O-RING | 1 | SN: 4001- |
