| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (21W-60-41201) | MOTOR ASS'Y | 1 | SN: 4001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A0 TO Y1651-03A0. | ||||||
| ? | TZ507D1000-02 | • FINAL DRIVE ASS'Y | 1 | SN: 4001- |
|||
| ? | ☆ | • • SPINDLE KIT | 1 | SN: 4001- |
|||
| ? | ☆ | • • • SPINDLE ASS'Y | 1 | SN: 4001- |
|||
| ? | ☆ | • • • • SPINDLE | 1 | SN: 4001- |
|||
| ? | ☆ | • • • • FLANGE,END | 1 | SN: 4001- |
|||
| ? | TZ500D1019-00 | • • • BOLT,REAMER | 3 | SN: 4001- |
|||
| ? | ☆ | • • RV GEAR | 1 | SN: 4001- |
|||
| ? | ☆ | • • • RV GEAR KIT | 1 | SN: 4001- |
|||
| ? | ☆ | • • • • RV GEAR | 1 | SN: 4001- |
|||
| ? | ☆ | • • • • RV GEAR | 1 | SN: 4001- |
|||
| ? | ☆ | • • • SHAFT,CRANK | 3 | SN: 4001- |
|||
| ? | ☆ | • • • SPACER | 6 | SN: 4001- |
|||
| ? | ☆ | • • • BEARING | 6 | SN: 4001- |
|||
| ? | ☆ | • • • BEARING | 6 | SN: 4001- |
|||
| ? | TZ507D1107-00 | • • SPUR GEAR KIT | 1 | SN: 4001- |
|||
| ? | ☆ | • • • SPUR GEAR | 3 | SN: 4001- |
|||
| ? | TZES20423232-B | • • FLOATING SEAL ASS'Y | 1 | SN: 4001- |
|||
| ? | TZES100-204-B | • • • SEAL,FLOATING (KIT) | 2 | SN: 4001- |
|||
| ? | TZ507D1001-00 | • • HUB,MOTOR | 1 | SN: 4001- |
|||
| ? | TZ507D1006-00 | • • GEAR | 1 | SN: 4001- |
|||
| ? | TZ500D1008-00 | • • COVER | 1 | SN: 4001- |
|||
| ? | TZ500D1015-00 | • • SHAFT | 1 | SN: 4001- |
|||
| ? | TZ500D1017-00 | • • PIN | 28 | SN: 4001- |
|||
| ? | TZ810B1018-00 | • • RING | 1 | SN: 4001- |
|||
| ? | ☆ | • • SNAP RING SET | 3 | SN: 4001- |
|||
| ? | ☆ | • • BEARING | 2 | SN: 4001- |
|||
| ? | TZJB2804-S19 | • • RING,SNAP | 1 | SN: 4001- |
|||
| ? | 04064-02512 | • • RING,SNAP | 6 | SN: 4001- |
|||
| ? | 07000-11008 | • • O-RING (KIT) | 2 | SN: 4001- |
|||
| ? | 07000-15230 | • • O-RING (KIT) | 1 | SN: 4001- |
|||
| ? | TZJW1516-G35-7 | • • O-RING (KIT) | 1 | SN: 4001- |
|||
| ? | TZ410D1033-01 | • • PLUG | 1 | SN: 4001- |
|||
| ? | TZ810B2021-00 | • • PLUG | 2 | SN: 4001- |
|||
| ? | 07000-12014 | • • O-RING (KIT) | 3 | SN: 4001- |
|||
| ? | 04260-00952 | • • BALL | 1 | SN: 4001- |
|||
| ? | TZJ1354-8-22 | • • PIN | 2 | SN: 4001- |
|||
| ? | SERVICE KIT | ||||||
| ? | (TZ505D9000-00) | SEAL KIT | 1 | SN: 4001- |
