| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (☉707-00-XC020) | CYLINDER GROUP,(VIOLET BLUE) | 1 | SN: 4001- |
|||
| ? | (☉707-00-XC010) | CYLINDER GROUP,(NATURAL YELLOW) | 1 | SN: 4001- |
|||
| ? | ==================== | ||||||
| ? | 707-00-0A630 | CYLINDER ASS'Y,BOOM | 1 | SN: 4001- |
|||
| ? | 721-11-11980 | • CYLINDER | 1 | SN: 4001- |
|||
| ? | 707-76-65520 | • BUSHING | 1 | SN: 4001- |
|||
| ? | 07145-00065 | • SEAL,DUST (KIT) | 2 | SN: 4001- |
|||
| ? | 707-29-11851 | • HEAD,CYLINDER | 1 | SN: 4001- |
|||
| ? | 707-52-10660 | • BUSHING | 1 | SN: 4001- |
|||
| ? | 707-51-65211 | • PACKING,ROD (KIT) | 1 | SN: 4001- |
|||
| ? | 144-63-92170 | • SEAL,DUST (KIT) | 1 | SN: 4001- |
|||
| ? | 07179-12079 | • RING,SNAP | 1 | SN: 4001- |
|||
| ? | 07000-12110 | • O-RING (KIT) | 1 | SN: 4001- |
|||
| ? | 707-35-91630 | • RING,BACK-UP (KIT) | 1 | SN: 4001- |
|||
| ? | 07000-12115 | • O-RING (KIT) | 1 | SN: 4001- |
|||
| ? | 07000-12110 | • O-RING (KIT) | 1 | SN: 4001- |
|||
| ? | 707-35-91610 | • RING,BACK-UP (KIT) | 2 | SN: 4001- |
|||
| ? | 707-58-65870 | • ROD,PISTON | 1 | SN: 4001- |
|||
| ? | 707-76-60710 | • BUSHING | 1 | SN: 4001- |
|||
| ? | 07145-00060 | • SEAL,DUST (KIT) | 2 | SN: 4001- |
|||
| ? | 707-71-70720 | • PLUNGER | 1 | SN: 4001- |
|||
| ? | 707-36-11610 | • PISTON | 1 | SN: 4001- |
|||
| ? | 707-44-11280 | • RING,PISTON (KIT) | 1 | SN: 4001- |
|||
| ? | 707-39-11510 | • RING,WEAR (KIT) | 1 | SN: 4001- |
|||
| ? | 707-67-45010 | • NUT | 1 | SN: 4001- |
|||
| ? | 02896-11012 | • O-RING (KIT) | 2 | SN: 4001- |
|||
| ? | 707-86-46910 | TUBE | 1 | SN: 4001- |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 4001- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 4001- |
|||
| ? | 02896-11012 | O-RING (KIT) | 1 | SN: 4001- |
|||
| ? | ==================== | ||||||
| ? | SERVICE KIT | ||||||
| ? | 707-98-36700 | SERVICE KIT,BOOM CYLINDER | 1 | SN: 4001- |
