| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-3T-00217 | PUMP ASS'Y | 1 | SN: 4767-5500 |
|||
| ? | 708-3T-00216 | PUMP ASS'Y | 1 | SN: 4605-4766 |
|||
| ? | 708-3T-00215 | PUMP ASS'Y | 1 | SN: 4001-4604 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-11A0 TO Y1600-14A0. | ||||||
| ? | 708-3T-01116 | • PUMP SUB ASS'Y | 1 | SN: 4767-5500 |
|||
| ? | 708-3T-01115 | • PUMP SUB ASS'Y | 1 | SN: 4605-4766 |
|||
| ? | 708-3T-01114 | • PUMP SUB ASS'Y | 1 | SN: 4001-4604 |
|||
| ? | 708-3T-04120 | • • CASE ASS'Y | 1 | SN: 4001-5500 |
|||
| ? | ☆ | • • • CASE,PUMP | 1 | SN: 4001-5500 |
|||
| ? | ☆ | • • • PLUG | 14 | SN: 4001-5500 |
|||
| ? | 07044-12412 | • • PLUG | 1 | SN: 4001-@ |
|||
| ? | 07002-62434 | • • O-RING | 1 | SN: 4001-@ |
|||
| ? | 04530-11018 | • • BOLT,EYE | 1 | SN: 4001-@ |
|||
| ? | (★720-68-19610) | • • PIN | 1 | SN: 4001-@ |
|||
| ? | (★708-3T-14151) | • • PLUG | 2 | SN: 4001-@ |
|||
| ? | (★708-3T-14170) | • • BALL | 2 | SN: 4001-@ |
|||
| ? | (★708-3T-14160) | • • SEAT | 2 | SN: 4001-@ |
|||
| ? | 07002-61023 | • • O-RING | 2 | SN: 4001-@ |
|||
| ? | 708-8E-16150 | • • PLUG | 3 | SN: 4001-@ |
|||
| ? | 07002-61023 | • • O-RING | 3 | SN: 4001-@ |
|||
| ? | 708-7R-11220 | • • PLUG | 2 | SN: 4001-5500 |
|||
| ? | 07002-11223 | • • O-RING | 2 | SN: 4001-5500 |
|||
| ? | (★708-3T-11310) | • • ORIFICE | 2 | SN: 4001-5500 |
|||
| ? | (★708-3T-12110) | • • SHAFT | 1 | SN: 4001-5500 |
|||
| ? | (★708-1W-22140) | • • BEARING | 1 | SN: 4001-@ |
|||
| ? | (★708-23-05011) | • • WASHER KIT | 1 | SN: 4001-@ |
|||
| ? | ☆ | • • • WASHER ? 2.60MM | 1 | SN: 4001-@ |
|||
| ? | ☆ | • • • WASHER ? 2.70MM | 1 | SN: 4001-@ |
|||
| ? | ☆ | • • • WASHER ? 2.80MM | 1 | SN: 4001-@ |
|||
| ? | ☆ | • • • WASHER ? 2.50MM | 1 | SN: 4001-@ |
|||
| ? | (★708-23-12840) | • • RING,SNAP | 1 | SN: 4001-@ |
|||
| ? | (★708-1W-22320) | • • BEARING | 1 | SN: 4001-@ |
|||
| ? | 708-8D-12221 | • • SEAL,OIL | 1 | SN: 4001-@ |
|||
| ? | 708-3T-12210 | • • CASE | 1 | SN: 4001-@ |
|||
| ? | 07000-12065 | • • O-RING | 1 | SN: 4001-@ |
|||
| ? | 04065-07225 | • • RING,SNAP | 1 | SN: 4001-@ |
