| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-15-8202 | EXHAUST BRAKE | 1 | SN: 20467-@ |
|||
| ? | □6162-15-8201 | EXHAUST BRAKE | 1 | SN: 18979-20466 |
|||
| ? | JK281-05017 | • BRAKE VALVE ASS'Y | 1 | SN: 20467-21782 |
|||
| ? | □JK281-05013 | • BRAKE VALVE ASS'Y | 1 | SN: 18979-20466 |
|||
| ? | ☆ | • • BODY | 1 | SN: 19125-21782 |
|||
| ? | ☆ | • • BODY | 1 | SN: 18979-19124 |
|||
| ? | ☆ | • • BUSHING | 1 | SN: 18979-21782 |
|||
| ? | ☆ | • • SHAFT | 1 | SN: 18979-21782 |
|||
| ? | JK281-24184 | • • VALVE | 1 | SN: 20467-21782 |
|||
| ? | JK281-24143 | • • VALVE | 1 | SN: 19125-20466 |
|||
| ? | JK281-24111 | • • VALVE | 1 | SN: 18979-19124 |
|||
| ? | ☆ | • • BUSHING | 1 | SN: 18979-21782 |
|||
| ? | JK1100-0725 | • • BOLT | 2 | SN: 18979-21782 |
|||
| ? | ☆ | • • SEAL,RING | 3 | SN: 18979-21782 |
|||
| ? | ☆ | • • SEAL,RING | 3 | SN: 18979-21782 |
|||
| ? | JK281-20529 | • • COVER | 1 | SN: 19125-21782 |
|||
| ? | JK281-20535 | • • COVER | 1 | SN: 18979-19124 |
|||
| ? | JK281-24375 | • • PLATE | 1 | SN: 18979-21782 |
|||
| ? | JK1100-0760 | • • BOLT | 2 | SN: 18979-21782 |
|||
| ? | JK0151-0805 | • • NUT | 2 | SN: 18979-21782 |
|||
| ? | JK1105-0047 | • • BOLT,FLANGE | 2 | SN: 18979-21782 |
|||
| ? | JK1105-0047 | • • BOLT,FLANGE | 3 | SN: 18979-21782 |
|||
| ? | JK1113-0285 | • • NUT,FLANGE | 1 | SN: 18979-21782 |
|||
| ? | JK281-22173 | • • LEVER | 1 | SN: 18979-21782 |
|||
| ? | JK284-01612 | • CONTROL ASS'Y | 1 | SN: 18979-21782 |
|||
| ? | JK284-10707 | • • CYLINDER ASS'Y | 1 | SN: 18979-21782 |
|||
| ? | ☆ | • • • CYLINDER | 1 | SN: 18979-21782 |
|||
| ? | JK1306-0081 | • • • SEAL,DUST | 1 | SN: 18979-21782 |
|||
| ? | JK1411-0591 | • • • SPRING | 1 | SN: 18979-21782 |
|||
| ? | JK284-20621 | • • • SHAFT | 1 | SN: 18979-21782 |
|||
| ? | JK284-22105 | • • • PROTECTOR,CYLINDER | 1 | SN: 18979-21782 |
|||
| ? | ☆ | • • • BUSH | 1 | SN: 18979-21782 |
|||
| ? | JK284-24503 | • • PISTON | 1 | SN: 18979-21782 |
|||
| ? | JK284-22007 | • • RING,WEAR | 1 | SN: 18979-21782 |
|||
| ? | JK1310-0264 | • • PACKING,CUP | 1 | SN: 18979-21782 |
|||
| ? | JK1132-0255 | • • WASHER | 1 | SN: 18979-21782 |
|||
| ? | JK1113-0285 | • • NUT,FLANGE | 1 | SN: 18979-21782 |
|||
| ? | JK1173-0016 | • • O-RING | 1 | SN: 18979-21782 |
|||
| ? | JK284-20507 | • • COVER | 1 | SN: 18979-21782 |
|||
| ? | JK0801-0820 | • • BOLT,WITH WASHER | 2 | SN: 18979-21782 |
|||
| ? | JK652-21900 | • • FILTER | 1 | SN: 18979-21782 |
|||
| ? | JK0410-1210 | • • RING,RETAINING | 1 | SN: 18979-21782 |
|||
| ? | JK284-22203 | • • GUIDE | 1 | SN: 18979-21782 |
|||
| ? | ☆ | • • PROTECTOR | 1 | SN: 18979-21782 |
|||
| ? | ☆ | • • LABEL | 1 | SN: 18979-21782 |
|||
| ? | JK1105-0166 | • BOLT | 2 | SN: 18979-21782 |
|||
| ? | JK1113-0281 | • NUT | 2 | SN: 18979-21782 |
|||
| ? | JK1291-0200 | • CLEVIS | 1 | SN: 18979-21782 |
|||
| ? | JK1155-0074 | • PIN | 2 | SN: 18979-21782 |
|||
| ? | JK286-20111 | • PIN | 2 | SN: 18979-21782 |
|||
| ? | JK286-20649 | • INSULATOR | 1 | SN: 18979-21782 |
|||
| ? | ☆ | • LABEL | 1 | SN: 20467-21782 |
|||
| ? | ☆ | • LABEL | 1 | SN: 18979-20466 |
