| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-15-8200 | EXHAUST BRAKE | 1 | SN: 17389-18978 |
|||
| ? | JK281-02456 | • BRAKE VALVE ASS'Y | 1 | SN: 18062-18978 |
|||
| ? | □JKX7972-056 | • BRAKE VALVE ASS'Y | 1 | SN: 17389-18061 |
|||
| ? | JK281-24213 | • • BODY | 1 | SN: 17389-18978 |
|||
| ? | JK1261-0146 | • • BUSHING | 1 | SN: 17389-18978 |
|||
| ? | JK281-24009 | • • SPINDLE | 1 | SN: 18062-18978 |
|||
| ? | JKX7972-386 | • • SPINDLE | 1 | SN: 17389-18061 |
|||
| ? | JK281-24129 | • • VALVE | 1 | SN: 18062-18978 |
|||
| ? | JK281-24109 | • • VALVE | 1 | SN: 17389-18061 |
|||
| ? | JK281-24008 | • • SPINDLE | 1 | SN: 18062-18978 |
|||
| ? | JKX7972-372 | • • SPINDLE | 1 | SN: 17389-18061 |
|||
| ? | JK1261-0147 | • • BUSHING | 1 | SN: 17389-18978 |
|||
| ? | JK1330-0022 | • • SEAL,RING | 2 | SN: 17389-18978 |
|||
| ? | JK1330-0018 | • • SEAL,RING | 2 | SN: 17389-18978 |
|||
| ? | JK281-20900 | • • GASKET | 1 | SN: 17389-18978 |
|||
| ? | JK281-20513 | • • COVER | 1 | SN: 17389-18978 |
|||
| ? | JK281-24324 | • • PLATE | 1 | SN: 18062-18978 |
|||
| ? | JKX7972-373 | • • PLATE | 1 | SN: 17389-18061 |
|||
| ? | JK1100-0675 | • • BOLT | 2 | SN: 17389-18978 |
|||
| ? | JK0111-0605 | • • NUT | 2 | SN: 17389-18978 |
|||
| ? | JK0801-0816 | • • BOLT,WITH WASHER | 2 | SN: 17389-18978 |
|||
| ? | JK0801-0816 | • • BOLT,WITH WASHER | 3 | SN: 17389-18978 |
|||
| ? | JK221-30200 | • • NUT,WITH WASHER | 1 | SN: 17389-18978 |
|||
| ? | JK281-21062 | • • LEVER | 1 | SN: 17389-18978 |
|||
| ? | JK284-01513 | • CONTROL ASS'Y | 1 | SN: 18062-18978 |
|||
| ? | □JK284-01506 | • CONTROL ASS'Y | 1 | SN: 17389-18061 |
|||
| ? | JK284-10705 | • • CYLINDER ASS'Y | 1 | SN: 18062-18978 |
|||
| ? | □JK284-10702 | • • CYLINDER ASS'Y | 1 | SN: 17389-18061 |
|||
| ? | JK284-20123 | • • • CYLINDER | 1 | SN: 18062-18978 |
|||
| ? | JK284-20108 | • • • CYLINDER | 1 | SN: 17389-18061 |
|||
| ? | JK1306-0081 | • • • SEAL,DUST | 1 | SN: 17389-18978 |
|||
| ? | JK1411-0406 | • • • SPRING | 1 | SN: 17389-18978 |
|||
| ? | JK284-20632 | • • • SHAFT | 1 | SN: 17389-18978 |
|||
| ? | JK284-22105 | • • • PROTECTOR,CYLINDER | 1 | SN: 17389-18978 |
|||
| ? | JK1261-0237 | • • • BUSHING | 1 | SN: 17389-18978 |
|||
| ? | JK284-20706 | • • PLATE | 1 | SN: 17389-18978 |
|||
| ? | JK284-22001 | • • RING,WEAR | 1 | SN: 17389-18978 |
|||
| ? | JK284-20807 | • • PACKING | 1 | SN: 17389-18978 |
|||
| ? | JK284-20900 | • • RETAINER | 1 | SN: 17389-18978 |
|||
| ? | JK1134-0039 | • • WASHER | 1 | SN: 17389-18978 |
|||
| ? | JK221-30200 | • • NUT,WITH WASHER | 1 | SN: 17389-18978 |
|||
| ? | JK1173-0016 | • • O-RING | 1 | SN: 17389-18978 |
|||
| ? | JK284-20507 | • • COVER | 1 | SN: 17389-18978 |
|||
| ? | JK0801-0820 | • • BOLT,WITH WASHER | 2 | SN: 17389-18978 |
|||
| ? | JK284-20401 | • • COVER | 1 | SN: 17389-18978 |
|||
| ? | JK284-22203 | • • GUIDE | 1 | SN: 17389-18978 |
|||
| ? | JK1272-0113 | • • PROTECTOR | 1 | SN: 17389-18978 |
|||
| ? | JK1391-2099 | • • LABEL | 1 | SN: 17389-18978 |
|||
| ? | JK0021-1060 | • BOLT | 2 | SN: 17389-18978 |
|||
| ? | JK0141-1008 | • NUT | 2 | SN: 17389-18978 |
|||
| ? | JK0303-1025 | • WASHER | 2 | SN: 17389-18978 |
|||
| ? | JK1291-0200 | • CLEVIS | 1 | SN: 17389-18978 |
|||
| ? | JK1155-0074 | • PIN | 2 | SN: 17389-18978 |
|||
| ? | JK286-20111 | • PIN | 2 | SN: 17389-18978 |
|||
| ? | JK286-20600 | • INSULATOR | 1 | SN: 17389-18978 |
|||
| ? | JK1391-0581 | • LABEL | 1 | SN: 18062-18978 |
|||
| ? | JK1391-0588 | • LABEL | 1 | SN: 17389-18061 |
