| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-54-8550 | CLIP | 3 | SN: 17389-@ |
|||
| ? | 6162-53-8510 | TUBE | 1 | SN: 17389-@ |
|||
| ? | 6162-53-8571 | TUBE | 1 | SN: 17389-@ |
|||
| ? | 6162-53-8520 | NIPPLE | 1 | SN: 17389-@ |
|||
| ? | 6136-11-5120 | SPACER | 3 | SN: 17389-@ |
|||
| ? | 07214-50813 | CONNECTOR | 2 | SN: 17389-@ |
|||
| ? | 07214-51013 | CONNECTOR | 2 | SN: 17389-@ |
|||
| ? | 01011-81025 | BOLT | 3 | SN: 17389-@ |
|||
| ? | 01643-31032 | WASHER | 3 | SN: 17389-@ |
|||
| ? | 6162-53-8531 | FLANGE | 1 | SN: 17389-@ |
|||
| ? | 07043-70211 | PLUG | 1 | SN: 17389-@ |
|||
| ? | 01010-81040 | BOLT | 2 | SN: 17389-@ |
|||
| ? | 6151-51-8161 | GASKET (K1) | 2 | SN: 17389-@ |
|||
| ? | 6162-53-8581 | HOSE | 1 | SN: 17389-@ |
|||
| ? | 6162-53-8590 | FLANGE | 1 | SN: 17389-@ |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 17389-@ |
|||
| ? | 6162-13-4471 | TUBE,DRAIN | 1 | SN: 17389-@ |
|||
| ? | 6162-13-4461 | TUBE,DRAIN | 1 | SN: 17389-@ |
|||
| ? | 6151-51-8151 | GASKET (K1) | 2 | SN: 17389-@ |
|||
| ? | 01010-81025 | BOLT | 4 | SN: 17389-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 17389-@ |
|||
| ? | 6162-13-4480 | CONNECTOR | 1 | SN: 17389-@ |
|||
| ? | 07281-00419 | CLAMP | 4 | SN: 17389-@ |
|||
| ? | 6162-54-8860 | HOSE | 2 | SN: 17389-@ |
|||
| ? | 6127-51-6822 | GASKET (K1) | 1 | SN: 17389-@ |
|||
| ? | 01010-81035 | BOLT | 2 | SN: 17389-@ |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 17389-@ |
